JIMI GT06E fleet smart gps tracker car mini gps GPS LBS positioning Hidden LED IPX5 waterproof navigation
- Category: >>>
- Supplier: Shenzhen Jimi Iot Co. Ltd.
Share on (60791348902):
Product Overview
Description
JIMI Fleet Management Solutions
Optimize your fleet and keep costs down
Dynamic growth of automotive branch enables greater access to means of transport. Most companies have, smaller or larger, vehicle fleet to carry out various tasks. Understanding costs related to the vehicle maintenance, fuel consumption, driver performance, insurance and service is an important function for any business.
HARDWARE
GT06E 3G Multifunctional GPS Tracker
GT06E GPS tracker is smart and multifunctional tracker with 3G cellular network, internal HSPDA and GSM antenna, RFID reader and fuel level sensor, etc. Features such as multiple alarms, SOS emergency call, voice monitoring and so on, make it perfect for logistics, fleet, assets and auto finance management. GT06E would update location information according to your set. Combined with the tracking platform and APP, you can view real time vehicles status, locate your car, get 3D live street view and replay history route, and be notified of alerts on your smartphone in time, providing comprehensive safety. Based on reliable technologies and favorable price, GT06E has enjoyed worldwide popularity and great customer reviews since launch. In addition, it has one-year warranty service, getting rid of any worries.
Features:
●GSM Quad-band
●GPS + GSM + GPRS wireless network
●High sensitive GPS chipset
●Real-time tracking
●Built-in GSM & GPS antenna
●Built-in ON / OFF power, wide voltage input range
●Built-in acceleration sensor for vibration alarm
●Support ACC detection, real-time reporting car status
●GPS + GSM + GPRS wireless network
●High sensitive GPS chipset
●Real-time tracking
●Built-in GSM & GPS antenna
●Built-in ON / OFF power, wide voltage input range
●Built-in acceleration sensor for vibration alarm
●Support ACC detection, real-time reporting car status
●Built-in 450mAh battery for alarm when the power supply is disconnected unexpectedly
●Tele-cut off (petrol / electricity) function
●SOS button for SOS alarm
●Voice monitor function
●Built-in CPU, eliminating breakdown automatically
●Three LED indicators: GPS - Blue; GSM - Green; Power - Red
●Check location via platform
●Tele-cut off (petrol / electricity) function
●SOS button for SOS alarm
●Voice monitor function
●Built-in CPU, eliminating breakdown automatically
●Three LED indicators: GPS - Blue; GSM - Green; Power - Red
●Check location via platform
Specifications:
GSM Specification | ||
Communication system | 850/900/1800/1900 MHz | |
Frequency | Class 12, TCP/IP | |
GPRS | 32+32Mb | |
Memory | RMSPE<5,PPE<20 | |
WCDMA | GSM850/GSM900:33±3dBm GSM1800/GSM1900:30±3dBm | |
Output power | ±0.1ppm | |
Receive sensitivity | GSM< -106dBm, WCDMA< -108dBm | |
GPS Specification | ||
GPS chipset | MTK high sensitivity chip | |
Frequency | L1,1575.42MHz C/A code | |
GPS channel | 66 | |
Location accuracy | <10 meters | |
Tracking sensitivity | -165dBm | |
Acquisition sensitivity | -148dBm | |
TTFF (open sky) | Avg. hot start ≤1sec Avg. cold start ≤38sec | |
Others | ||
Monitoring scope | ≤5M | |
Antenna | Built-in GPS ceramic antenna; GSM quad-band antenna | |
LED indicator | GPS(blue), GSM(green), Power(red) | |
Operating voltage | 9-36VDC | |
Built-in battery | 450mAh/3.7V industrial lithium polymer battery | |
Standby time | 60 hours | |
Working time | 4 hours | |
Operating temperature | -20℃～70℃ | |
Operating humidity | 5%~95%, non-dense | |
Dimension | 98.0(L)*52.0(W)*15.0(H)mm | |
Weight | 80g | |
