Hot air seam sealing sewing machine for Marine Suits Sleeping Bags Car

==Product Features==

1. Main parts with complete set of highly reliable imported elecfrical components,panasonic’s PLC and proframmable LCD,decrease trouble rate


2. Humanized operation panel,programmable parameter setting,LCD and operation regulation display for simplified debugging.


3. Auto controllable temperature with high stability slightly varies between±2°C, Warning device for
   temperature upper limit is installed to protect heating wire.


4. Blowing-in wind can be filtrated without oil or water by unique heater tube.


5. The functions of auto tape clipping, sending and finishing reduce the wastage of raw material.


6. Collecting advantages of machines from oversea and country,adopting of mature and advanced technique in machine and electrics.


7. Be possible of working24 hours continuously and produce highly efficiently.

==Technical parameter==

Power cosumption:

AC~220V 50Hz 2500W Abt

Heater power:

2000W of special heating elements

Heater control:

Infinitely variable up to 700^oC

Speed:

2~24m/min infinitey variable

Air supply:

0.35~0.5 Mpa

Width of pinch roller:

25mm standard with options for plain points engraved and striped roller

Width of seam sealing tape:

Standard 14mm ~22mm ,other optional

Upper roller lift:

18mm~25mm

Exterior size:

(L)1350mm×(W)600mm×(H)1530mm

Net weight:

140kg

Prevention against jumping over sewing work:

There are adjustable devices to prevent the gun from jumping over the seamed sections when the gun is  moving in ward with the idle wheel starting,or when the gun moving outward with the idle wheel stopping.
