Product Overview
Description
Buy Atlas Copco Surface Drill Rigs ROC in China
Atlas Copco Drill rigs and rock drills (AC Drill rigs and rock drills ) T2W Water Well Drill: Water Well Drills
More features were designed into the T2W than any machine in its class, providing the benefits of larger, more expensive drilling rigs. With its open work area, excellent control of feed speed and exceptional on and off road mobility, the T2W is not only perfectly suited for water well drilling but also for a wide variety of environmental, air rotary and DTH drilling. The Atlas Copco T2W is a lightweight, truck-powered water well drill designed for air/mud applications.
Features & benefits
- A high-speed feed system equally fast in both directions to reduce time spent adding drill pipe and tripping from the hole
- An internal guide system to assure alignment and promote longer component life
- A smooth, responsive feed control for precise, trouble-free drilling
Technical data
| echnical Specifications | |
|---|---|
| Compressor pressure | 300 psi / 2,068 kPa standard on large base machine 200 psi / 1,379 kPa optional small base machine |
| Compressor flow (text) | 750 cfm / 21.24 m3 standard on large base machine 400 cfm / 11.33 m3 optional small base machine |
| Deck engine/PTO drive | CAT C-13, 425 HP @ 2100 RPM, 1550 ft-lb. @ 1200 RPM IHC DT570, 310 HP @ 2200 RPM, 950 ft-lb. @ 1200 RPM |
| Pullback | 13608 kg |
TH60
Truck Engine/PTO Water Well drill - DTH, Rotary air, and mud drilling
Single engine design
Reduced noise and deck congestion
Improved weight balance
IT'S ALL ABOUT DOING MORE FOR LESS.
Epiroc’s TH60 water well rig is designed to help a crew work safer and faster with less manual labor.
With up to 600 hp (477 kW) under the hood and 1850 ft-lb (2508 Nm) of torque to the rear wheels, the TH60 moves along at highway speeds, delivering the power to move in mountainous locations without continuously downshifting, as well as ample torque throughout its range of gears on the jobsite.
Truck Engine/PTO Water Well drill - DTH, Rotary air, and mud drilling; Pullback capacity 177.9 kN (40,000 lbs); Pulldown capacity 111.2 kN (25,000 lbs)
- Flexible, adaptive CycloneTM Operating system allows you to tackle easy or tough jobs with equal confidence
- Adaptive pipe handling includes a carousel or single pipe loader, drawworks, hoist plug, optional pipe spinner and two-part line
- Choice of two ways to set casing
Downloads
reference book on deephole drilling
Deephole Drilling19.7 MB, PDFTH60 TH60DH water well drills brochure
TH60_TH60DH Brochure442.5 KB, PDFTH60DH Cyclone brochure
TH60DH Cyclone1.7 MB, PDF
| Technical specifications | Imperial | Metric |
| Compressor pressure | 120 to 350 psi | 8.3 to 24.1 bar |
| Compressor flow (text) | 900 or 1070 cfm | 425 l/s or 505 l/s |
| PTO drive | Cummins ISX, 600 Hp @ 1800 RPM | Cummins ISX, 447 kW @ 1800 RPM |
| Pullback | 40000 lb | 18144 kg |
| Pulldown | 25,000 lb | 11,340 kg |
TH5
Lightweight Water Well Drill
Modular design
DTH & Mud drilling
Serviceabilty
Epiroc lightweight water well drill rigs have been designed to withstand aggressive, rugged environments.
Built to Epiroc's high standards with world renowned branded compnents our rigs have a history or longevity.
Epiroc TH5 is smallest in the Lightweight water well rig range for drilling shallow wells upto 320ft (100m). It can be mounted on 4x2 truck or trailer.
Perfectly designed module with its own powerpack the TH5 can be sold along with a truck or as a module for the customer to mount on the truck of their preference.
A
| Technical specification | Imperial | Metric | |||
| Pullback | 5000 lbs | 22.29 kN | |||
| Deck engine | Deutz aircooled, 3 Cylinder, 59 hp (44 kW) at 2500 rpm | Deutz aircooled, 3 Cylinder, 59 hp (44 kW) at 2500 rpm | |||
Downloads
TH5 water well drill rig
TH5 Brochure3 MB, PDFreference book on deephole drilling
Deephole Drilling
TH10LM OBC
Lightweight Water Well Drill
Onboard Mud and Air
Powerfull rotation head
Reliable feed system
Epiroc Lightweight waterwell rigs are designed to withstand the tougest drilling conditions.
Built to Epiroc's high standards with world renowned branded compnents our rigs have a history or longevity.
Epiroc’s TH 10 drill module is a hydraulically operated, mobile water well drill ideally suited for small-to-medium sized projects in remote village well drilling programs or shallow irrigation well drilling.
Epiroc TH10 Lightweight waterwell rig has proven its performance for drilling shallow wells upto 650 ft (200m) for last many years in various formations sucessfully.
| Technical specifications | Imperial | Metric | |||
| Pullback | 15000 lbs | 66,72 kN | |||
| Deck engine | Deutz aircooled, 6 Cylinder, 135 hp (104 kW) at 2000 rpm | Deutz aircooled, 6 Cylinder, 135 hp (104 kW) at 2000 rpm | |||
Downloads
reference book on deephole drilling
Deephole Drilling19.7 MB, PDFTH10 water well drill brochure
TH 10 Brochure
TH10LM
Lightweight Water Well Drill
Reliable feed system
Longer Mast
Operating Safety
Epiroc Lightweight waterwell rigs are designed to withstand the tougest drilling conditions.
Built to Epiroc's high standards with world renowned branded compnents our rigs have a history or longevity.
Epiroc’s TH 10LM (Long Mast) Lightweight waterwell rig is class apart for drilling wells upto 1000 ft (300m) for many household and agricultural needs with air and mud
| Technical specifications | Imperial | Metric | |||
| Pullback | 25000 lbs | 111 kN | |||
| Deck engine | Deutz aircooled, 6 Cylinder, 135 hp (104 kW) at 2000 rpm | Deutz aircooled, 6 Cylinder, 135 hp (104 kW) at 2000 rpm | |||
Downloads
reference book on deephole drilling
Deephole Drilling19.7 MB, PDFTH5 LM water well drill brochure
TH 10 LM Brochure
TH10 Lightweight Water Well Drill
Extendable Mast
Naturally aspirated deck engine
Sturdy Platform
Lightweight waterwell rigs are designed to withstand the tougest drilling conditions.
Built to Epiroc's high standards with world renowned branded compnents our rigs have a history or longevity.
Epiroc Lightweight TH10LM (Long Mast ) OBC (Onboard Compressor) waterwell rig is largely used for drilling deeper wells upto 1000ft (300m) for household, agricultural and de-watering applications.
Lightweight Water Well drill - DTH, Rotary air and mud drilling;
Pullback capacity 66.7 (15 000lbf);
Pulldown capacity 40 kN (9000 lbf)
Epiroc TH10 Lightweight waterwell rig has proven its performance for drilling shallow wells upto 650 ft (200m) for last many years in various formations sucessfully.
| Technical specifications | Imperial | Metric | |||
| Pullback | 26000 lbs | 111 kN | |||
| Deck engine | Powered by truck engine | Powered by truck engine | |||
Downloads
reference book on deephole drilling
Deephole Drilling19.7 MB, PDFTH10 Lm OBC water well drill brochure
TH 10 LM OBC Brochure
T4W carrier mounted
Carrier mounted Water Well drill with deck engine - DTH, Rotary air, and mud drilling
Productive and reliable
Additional capacity and improved performance
Quick and safe casing handling
The Epiroc T4W continues its legacy with chassis and drill enhancements that raise the benchmark of water well drills.
Carrier mounted Water Well drill with deck engine - DTH, Rotary air, and mud drilling; Pullback capacity 311.4 kN (70,000 lbs) with regen; Pulldown capacity 133.4 kN (30,000 lbs)
| Technicl specifications | Imperial | Metric | |||
| Compressor pressure | 120 to 350 psi | 8.2 to 24.1 bar | |||
| Compressor flow | 1070 cfm | 504 l/s | |||
| Deck engine | Cummins QSX15 , 600 Hp @ 1800 RPM | Cummins QSX15 , 447 kW @ 1800 RPM | |||
| Pullback | 50 000 lb / 70 000 lb optional pullback W/regen. | 13 608 kg / 31 751 kg optional pullback W/regen. | |||
Downloads
T4W water well drill brochure
T4W Brochure498.6 KB, PDFreference book on deephole drilling
Deephole Drilling
T3WDH
Deck Engine Water Well drill - DTH, Rotary air, and mud drilling
A separate truck engine and a deck engine
Hands-free holding wrench
Foot-pedal activated top wrench
The T3WDH is designed to handle larger, deeper holes with larger diameter casing than the standard T3W.
With 1070/350 on-board air, 70,000 lb (31,751 kg) pullback and a 20 in (508 mm) table opening, this rig offers contractors an expanded application range and all of the proven T3W operating system advantages. The T3WDH has an impressive list of standard features including 37 ft 5 in (11.4 m) working clearance, which is long enough to drive 20 ft (6096 mm) casing with a DHD or to install a casing hammer. The full complement of optional equipment expands the T3WDH application range even further.
Deck Engine Water Well drill - DTH, Rotary air, and mud drilling; Pullback capacity 311.4 kN (70,000 lbs); Pulldown capacity 133.4 kN (30,000 lbs)
• Adaptive pipe handling includes a carousel and single pipe loader, as well as drawworks and a hoist plug
- Both fast feed and drawworks can be operated simultaneously to speed up the drilling process
- Tripping can be done with drawworks or rotary head
• The T3WDH utilizes a single 35 ft (10.6 m) derrick with 37 ft 5 in (11.4 m) working clearance. Supports air-mud-DHD drilling, casing hammer, dual wall pipe, simultaneous drill and drive with a DHD or driving casing from the top with a DHD.
| Technical specifications | Imperial | Metric | |||
| Compressor pressure | 350 psi | 24.1 bar | |||
| Compressor flow | 1070 cfm | 505 l/s | |||
| Deck engine | Caterpillar C15 575 Hp @ 1800 RPM | Caterpillar C15 425 kW @ 1800 RPM | |||
| Pullback | 70000 lb | 31751 kg | |||
| Pulldown | 30,000 lb | 13,608 kg | |||
Downloads
reference book on deephole drilling
Deephole Drilling19.7 MB, PDFT3W brochure
T3W brochure444.4 KB, PDFT3W Cyclone Operating System brochure
T3W Cyclone Operating System
T3W
Deck Engine Water Well drill - DTH, Rotary air, and mud drilling
Adaptive pipe handling
Separate truck engine and a deck engine
On-demand power
For over 100 years, Atlas Copco drills have had a major impact on the drilling community worldwide and have set the standard for quality, longevity, reliability, and performance.
The T3W sits right in the middle of the Epiroc water well line. A combination of old and new technology on the T3W boosts productivity, efficiency and fuel savings while providing the familiarity and reliability you expect from an Epiroc drill.
Deck Engine Water Well drill - DTH, Rotary air, and mud drilling; Pullback capacity 177.9 kN (40,000 lbs); Pulldown capacity 111.2 kN (25,000 lbs)
• Adaptive pipe handling that includes a carousel and single pipe loader, as well as drawworks and a hoist plug
• Single 35 ft (10.6 m) derrick with 37 ft 5 in (11,400 mm) working clearance
| Technical specifications | Imperial | Metric | |||
| Compressor pressure | 350 psi | 24.1 bar | |||
| Compressor flow (text) | 900 cfm or 1070 cfm | 425 l/s or 505 l/s | |||
| Deck engine | Caterpillar C15 - 575 Hp @ 1800 RPM | Caterpillar C15 - 575 Hp 428 kW @ 1800 RPM | |||
| Pullback | 40000 lb | 18144 kg | |||
| Pulldown | 25,000 lb | 11,340 kg | |||
Downloads
reference book on deephole drilling
Deephole Drilling19.7 MB, PDFT3W brochure
T3W brochure444.4 KB, PDFT3W Cyclone Operating System brochure
T3W Cyclone Operating System
T2W
Truck Engine/PTO Water Well drill - DTH, Rotary air, and mud drilling
A high-speed feed system
An internal guide system
A smooth, responsive feed control
BUILT TO THE HIGHEST STANDARDS
The Epiroc T2W has a long history as a robust, reliable water well drill rig. It is not by coincidence that customers choose the T2W when they are looking for a drill that delivers high productivity even in the most rugged conditions.
More features were designed into the T2W than any machine in its class, providing the benefits of larger drilling rigs. With its open work area, excellent control of feed speed and exceptional on and off road mobility, the T2W is not only perfectly suited for water well drilling but also for a wide variety of environmental, air rotary and DTH drilling.
Truck Engine/PTO Water Well drill - DTH, Rotary air, and mud drilling; Pullback capacity 133.4 kN (30,000 lbs); Pulldown capacity 133.4 kN (30,000 lbs)
| Technical specifications | Imperial | Metric | |||
| Pullback | 30000 lb | 13608 kg | |||
| Compressor pressure | 350 psi standard on large base 300 psi optional on small base | 2,413 kPa standard on large base 2,068 kPa optional on small base | |||
| Compressor flow | 900 cfm standard on large base 750 cfm optional on small base | 25,5 m3/min standard on large base 21,2 m3/min optional on small base | |||
| Truck engine | Cummins ISX15 550HP @ 2000 RPM Torque 1850 lb-ft @ 1200 RPM | Cummins ISX15 410 kW @ 2100 RPM Torque 2508 Nm @ 1200 RPM | |||
Downloads
reference book on deephole drilling
Deephole Drilling
Most relevant
11 products found
T2W
Truck Engine/PTO Water Well drill - DTH, Rotary air, and mud drilling; Pullback capacity 133.4 kN (30,000 lbs); Pulldown capacity 133.4 kN (30,000 lbs)
T3W
Deck Engine Water Well drill - DTH, Rotary air, and mud drilling; Pullback capacity 177.9 kN (40,000 lbs); Pulldown capacity 111.2 kN (25,000 lbs)
T3WDH
Deck Engine Water Well drill - DTH, Rotary air, and mud drilling; Pullback capacity 311.4 kN (70,000 lbs); Pulldown capacity 133.4 kN (30,000 lbs)
T4W carrier mounted
Carrier mounted Water Well drill with deck engine - DTH, Rotary air, and mud drilling; Pullback capacity 311.4 kN (70,000 lbs) with regen; Pulldown capacity 133.4 kN (30,000 lbs)
TH10
Lightweight Water Well drill - DTH, Rotary air and mud drilling; Pullback capacity 66.7 (15 000lbf); Pulldown capacity 40 kN (9000 lbf)
TH10LM
Lightweight Water Well drill - DTH, Rotary air and mud drilling; Pullback capacity 111 kN (25 000lbf); Pulldown capacity 66 kN (15000 lbf)
TH10LM OBC
Lightweight Water Well drill - DTH, Rotary air and mud drilling; Pullback capacity 111 kN (25000lbf); Pulldown capacity 66 kN (15000 lbf)
TH5
Lightweight Water Well drill - DTH, Rotary air and mud drilling; Pullback capacity 22.29 kN (5000lbf); Pulldown capacity 13.37 kN (3000 lbf)
TH60
Truck Engine/PTO Water Well drill - DTH, Rotary air, and mud drilling; Pullback capacity 177.9 kN (40,000 lbs); Pulldown capacity 111.2 kN (25,000 lbs)
TH60DH
Truck Engine/PTO Water Well drill - DTH, Rotary air, and mud drilling; Pullback capacity 311.4 kN (70,000 lbs); Pulldown capacity 133.4 kN (30,000 lbs)
Welldrill 3062
Geotechnical drilling rig
- Main application area : Geotechnical drilling
- Drilling method : Down-the-hole
- Rod length : 3 m
