Fayon Traffic Sign Making Flatbed Laminating Machine with Adjustable Leg
- Category: >>>
- Supplier: HENAN FAYON TECH. CO. LTD.
Share on (60792913910):
Product Overview
Description
Fayon Traffic Sign Making Flatbed Laminating Machine with Adjustable Leg
Product introduction:Fayon flatbed laminating machine
Fayon Flatbed laminating machine designed for the application of foil and all types of self-adhesive vinyl,
transfer film, cold lamination and mounting of images on panels.
Fayon flatbed laminating machine is an innovative flatbed laminator specially designed to enable easy and
precise applications of foil and self-adhesive vinyl on a wide variety of materials(e.g. sheet metal,
plastic, glass and banners). It is used as well for panels mounting and industrial applications.
Features for fayon flatbed LAMINATING MACHINE
1.LED table lighting system
2. Tension Media feed shafts
3.Heat assisted roller
3. Alloy aluminum structure
4. Silent air compressor
5.Mmedia roll holders
Advantages for fayon flatbed laminating machine
1.Reduce production time dramatically
2. Consistent high quality work flow
3. Time savings equals more profit
4. Ergonomically designed, easy to use
5.Only minimal training required to operate
6. Requires only one person to operate
Application for fayon flatbed laminating machine:
Mounting
It only takes one person to mount digital prints or adhesive stickers on to many form of sub-straights. Mount on foam board,
corrugated panels, metal panels, banners and glass, all without bubbles.
Laminating
The Surface table can also be use for post processing laminating in cold or heat assist modes.
Pre-masking
One person can pre-mask up to 60 inches wide or depending on the width of your table. Not a 2 person job anymore.
Work-Station
Of course the Surface can also be used for any of your signage uses. Trimming graphics, doing layouts, weeding. The
Surface can be a great support for your shop in speeding up jobs and efficency.
Parameter for fayon flatbed laminating machine:
Item | Fayon Flatbed laminating machine |
Model | FY1325/FY1530/FY1737 |
Diameter of roller: | 150mm |
Material of rollers: | Silicon dioxide Feature:thermostability,wear-resisting,anti-aging,moisture proof,Good elasticity,pollution-free, No Distortion |
Max.effective working size: | 1300mm*2500mm 1500mm*3000mm 1700mm*3700mm |
Table glass: | 12mm temper glass |
Illumination | LED tube illumination |
Guideways | V sharp bearings |
Machine frame | Alloy sluminum
|
Machine paint | Sprayed finished |
Material roll holder | In front and at behind durable material roll holder and also media roll holder on the gantry |
Max.filming thickness | 50mm |
Roller heating: | Internal heating by infrared |
Temperature range | Adjustable,environmental-60°C |
Warm up time | 10-15min |
Power Consumption | 0.8~1.0kw/h |
Power consumption | 2500w |
Laminating mode | Manual |
Pressure adjustable mode | Pneumatic/non-noise air compressor |
Input Frequency | 50-60 hz |
Rated input voltage | 110v/220v |
Gross weight of machine | 800KGS |
Package Material: | Plywood case with steels around for protection |
Warranty | Broken parts changed for free within one year |
Exhibition photos:
Package and delivery photos for fayon flatbed applicator:
