Scope: Applicable to the workers, the people drilling, ground drilling, with a large diameter drilling, drilling deep, footage fast, flexible mobile, suitable for wide geographical.
Technical Parameters
(Model)
HQZ200
Drilling dia.（mm)
100-254
Drilling depth（m)
200
Drilling direction （° )
to the ground 45°-90°
one time advance length of the drill（mm )
1500
Electric motor power（kw)
11
Drill swing speed（rpm )
52
Air Pressure（Mpa )
1.45-2.5
Air consumption（m3 /min)
15-27
Total weight（kg)
1600
Recommend Products
Product packaging
We can ship construction machinery by various transportation tools:
--- For 90% of our shipment will go by sea. --- For neighbor countries of China, we ship trucks by road or railway. --- For light spare parts in urgent demand, we choose International courier service, such as DHL, TNT, UPS.
