High Pressure 12038 4000rpm 120mm welding machine cooling fan 120X120X38mm 12V 24V 48V
- Category: >>>
- Supplier: Shenzhen Feng Zhi Yuan Electronics Co. Ltd.
Share on (60793576566):
Product Overview
Description
High Pressure 12038 4000rpm 120mm welding machine cooling fan 120X120X38mm 12V 24V 48V
Product Description
| Model | Rated Voltage | Voltage Range | Current | Power | Speed | Air Flow | Pressure | Noise | ||
| VDC | VDC | Amp | Watts | RPM | m³/min | CFM | mm Aq | In H2O | dBA | |
| FD1238B4U-AT00 | 24 | 12~26.4 | 1.80 | 43.20 | 5000 | 7.37 | 260.4 | 33.44 | 1.32 | 67.8 |
| FD1238B4H-AT00 | 1.20 | 28.80 | 4500 | 6.65 | 235.1 | 27.26 | 1.07 | 64.3 | ||
| FD1238B4M-AT00 | 0.90 | 21.60 | 4000 | 5.91 | 208.7 | 21.54 | 0.85 | 61.4 | ||
| FD1238B4L-AT00 | 0.60 | 14.40 | 3500 | 5.22 | 184.6 | 16.78 | 0.66 | 58.2 | ||
| FD1238B2U-AT00 | 12 | 6~14 | 2.50 | 30.00 | 5000 | 7.37 | 260.4 | 33.44 | 1.32 | 67.8 |
| FD1238B2M-AT00 | 1.20 | 14.40 | 4000 | 5.91 | 208.7 | 21.54 | 0.85 | 61.4 | ||
| FD1238B2L-AT00 | 0.80 | 9.60 | 3500 | 5.22 | 184.6 | 16.78 | 0.66 | 58.2 | ||
About Us
Q1: Are you a factory or trading company ?
A1: We are a factory.
Q2: What is DC Fan and AC fan?
A2: DC fan is powered by DC voltage,normal voltage is 5V 12V 24V 48V 60V and72V.
AC fan is powered by AC voltage,normal voltage is 110V,220V and 380V.
Q3:How about the lifetime of fan?
A3:
Bearing type | Lifetime |
Dual Ball Bearing | 50000 hours |
Sleeve Bearing | 20000 hours |
Hydraulic Sleeve Bearing | 30000 hours |
Q4: What effects the quoted price for the fan?
A4:
Specification | Example |
1 size of the fan | 4010 (40*40*10mm) |
2 Voltage | 5V\\12V\\24V |
3 current | 0.15A |
4 speed | 8000RPM |
5 air flow | 8.6CFM |
6 noise | 24dBA |
7 bearing type | ball\\sleeve\\Hydraulic sleeve |
8 two wire or three wire | 2 wire |
9 cable length | 100mm |
10 connector type | 2 pin,2.5mm pitch |
11 function | FG\\RD\\PWM\\Soft Start ...... |
12 quantity | 100\\1000\\5000\\10000 ...... |
Q5:Certificate?
A5:FCC,CE, ROSH,ISO9001,ISO14001 Approved.
Q6:What is the delivery time?
A6:Sample lead time:3-5 days
Mass production delivery lead time:2-3 weeks(Depend on the quantity)
Q7:Delivery ways ?
A7:FedEx, DHL ,UPS,TNT Door to Door service ,By Air ,By Sea ,etc.
Q8:Payment terms ?
A8: By T/T or Paypal .
100% payment for sample orders .
30% as deposit and 70% balance before shipment .
Q9: What is the fan use for?
A9:
Office supplies | 3D printers |
Industry & Scientific | Stage lighting,VR equipment,Intelligent Manicure machine, Projector,High-speed camera,Head mounted display,Automotive industry, Cabinet industry, Power industry,UAV application, Electric forklift,LED lighting industry, Hand held air detector,Charging machine,Nebulizer. |
Home & Kitchen | Electromagnetic oven,Humidifier,Smart toilet,Intelligent household lampblack machine,Air purifier,Car GPS,Car LED lamp,Aromatherapy machine. |
Computer appliances | CPU cooler,Case. |
