Product Overview

Description


Product Description
1. Diameter of cylinder is 5 inch

2. Needle counts from 54N 72N 84N 96N 108N 120N 132N 144N 156N 168N 200N  are available.

3. Production Capacity/24 hours: 250~300 pairs according to different sizes or cosy socks

4. Max. 13 colors can be knitted in one sock

5. 3D socks, low-cut socks, plain& terry socks,cosy socks can be knitted

6. Length, density can be set up on the machine controller, patterns can be designed through the software

according to buyers' requirement. Therefore, sports socks, jacquard socks, casual socks, high knee socks

can be knitted

8.Double down pickers, double up pickers are adopted for a better and quicker heel-knitting
SPECIFICATION
\t
                 Cylinder diameter
\t
                                                                          5"
\t
                  Needle Number
\t
                                                               54N-240N
\t
                Maximum Speed
\t
                                                           250-280R.P.M
\t
                Driving Control
\t
                                                           Servo Motor
\t
    Servo driving/Motor power
\t
                                                               0.85kw
\t
                      Voltage
\t
                                                 380V/220V(optional)
\t
                  Main Motor
\t
                                                                1.3kw
\t
                       Fan
\t
                                                       >1.1kw(optional)
\t
                 Control box
\t
                                                              0.8kw
\t
                   Site area
\t
                                                    150*100*200cm
\t
                 Net Weight
\t
                                                               250KG
\t
             Gross Weight
\t
                                                              305KG
\t
             Package Size
\t
                                             90*75*160CM(1.08CBM)
\t
      Production Capacity
\t
                     250-300pairs/24hours according to different sizes of socks
configuration
Detailed Images
Optional

1. Suction fan motor 1.5kw (for small quantity of sock machine, below 10 sets, individual suction fan

motor is suggested, if over 10 sets, central suction fan motor is better, which can help save electricity

consumption greatly)

2. Solenoid on main feeders, sub-feeders, valve box

3. Double elastic motors, double elastic feeders

4. Invisible sock function

5. BTSR yarn break sensors

6. LGL or Chinese brand accumulators

7. Robert yarn creels

8. Power: 220V, 3-phase

9. Machine colors: blue or grey

Advantage

1. One Year Guarantee, Spare Parts are always available

2. Machines keep running for 24 hours

3. Professional Sales Team and After Sales Service Team

4. One Stop Shopping, the whole sock production line can be provided including spare parts, raw materials

Packing & Delivery

Packaging Details
plywood case
18 sets for a 20ft container
39 sets for a 40ft container


Port:  Ningbo or Shanghai
Lead Time : 20 working days after the deposit

Contact us

1. Could you please tell me what kind of socks will you want to make?
(the needles will be different)
For example, summer wearing or winter wearing?
And then, for which ages group? New born baby or children or adults? It will be great if you will show me the clear socks pictures together.


2. How to choose the suitable needle?
96N 108N 120N - usually baby socks
132N - teenagers' socks
144N- ladies or men's socks
156N 168N 200N - men's socks

3. Couid you please tell me how many machines will you want to try?
(the equipments will be different)
For example, 1 set for first try or 10 sets.

4. Could you please tell me your budget?
(the functions can be discussed)
For example, 3 thousand dollars, or 10 thousand dollars.
