Outdoor movable LED show truck LED show van

Product Name:

White Bird HXC5168XZS5 LED advertising vehicle

Announcement Batch:

295

Gross Weight:

15600KG

Rated Weight:

3970/3905/4470/4405KG

Curb Weight:

11500/11000KG

Max Speed:

90(km/h)

Approach/Departure Angle(°):

23/10,23/11

Front /Rear Suspension:

1328/2612,1340/2550

Passenger :

2,3

Number of Springs:

8/9+5,11/12+9,3/4+3,2/2+1,3/3+2

Fuel Type:

Diesel

Number of Tires:

6

Tire Specifications:

9.00-20,9.00R20,275/70R22.5,10R22.5

Front Tread:

1810,1916

Rear Tread:

1800

Number of Axes:

2

Wheelbase:

5100,4700

Dimensions(mm):

9040,8590*2550*3910(L*W*H)

Chassis Model:

LZ1160M3ABT/-/-/-

Container Size(mm):

//

Note:

Optional car body (see optional photos for details): LED screens can be installed on both sides of the car body (optional LED screen plus cover plate, optional front and rear cover with LED cooling cover) or no LED screen Structure, expandable side door; optional single door open at the back of the box. Vehicle length (mm) / wheelbase (mm) / front suspension (mm) / rear suspension (mm) / departure angle (°) / curb weight (kg) Correspondence: 9040/5100/1328/2612/10/ 11500, 8590/4700/1340/2550/11/11000. Rated load mass (kg) / number of passengers in the cab: 3970/2, 3905/3, 4470/2, 4405/3. The side guards and rear guards are of skirt-type structure. The guards are made of Q235A common carbon steel (thickness 1.5mm) bending combination welding. The guards are welded to the body and the rear guards are separated. The ground height is 480mm. ABS Model/Enterprise: ABS-E 4S/4M/ WABCO Automotive Control Systems, Inc. This car is a dedicated work vehicle for product display. The tire specifications of the car with the chassis are 9.00-20 16PR, 9.00R20 16PR, 275/70R22.5 16PR, 10R22.5 16PR.
