Z20 European Standard Cone Clamping Elements power lock
Product Description
Description:
Type Z20 is a keyless shaft power lock. It can replace single keyway and spline ,in order to realize the connection between machinery parts (such as gear wheel,flywheel) and shafts,so the loading can be transmitted.Through the function of high strength of bolt when locking device is working,enormous strengh of tight holding power between hub, inner loop and shaft are produced.When bearing the weight and loading depend on connection power between locking device and machinery and additional frictional torce to transmission torsion or power on shaft.
Parameter of Z20 European Standard Cone Clamping Elements power lock
DIMENSION
Bolt
Rated Load
Torque of
tighten
locking-bolt
MA
N·m
Weight
[Kg]
d
dw
D
L
L1
L2
d1
n
Torque
Mt
[kN·m]
Axial
Force
Ft [kN]
25 25 30 30 30
18 20 20 22 24
60 60 65 65 65
26 26 26 26 26
20 20 20 20 20
17 17 17 17 17
M6 M6 M6 M6 M6
9 9 9 9 9
0.19 0.255 0.205 0.27 0.34
21 25 20 24 28
17 17 17 17 17
0.37 0.37 0.42 0.42 0.42
35 35 35 40 40
25 28 30 30 32
72 72 72 78 78
26 26 26 26 26
20 20 20 20 20
17 17 17 17 17
M6 M6 M6 M6 M6
12 12 12 15 15
0.365 0.49 0.585 0.555 0.59
29 35 39 37 37
17 17 17 17 17
0.48 0.48 0.48 0.54 0.54
40 40 45 45 45
34 35 35 36 38
78 78 92 92 92
26 26 32 32 32
20 20 24 24 24
17 17 20 20 20
M6 M6 M8 M8 M8
15 15 12 12 12
0.71 0.77 0.96 1.03 1.2
42 44 55 57 63
17 17 41 41 41
0.54 0.54 0.92 0.92 0.92
50 50 50 55 55
38 40 42 42 45
98 98 98 105 105
32 32 32 32 32
24 24 24 24 24
20 20 20 20 20
M8 M8 M8 M8 M8
12 12 12 14 14
1.01 1.16 1.32 1.33 1.59
53 58 63 63 70
41 41 41 41 41
1 1 1 1.1 1.1
55 60 60 60
48 48 50 52
105 110 110 110
32 32 32 32
24 24 24 24
20 20 20 20
M8 M8 M8 M8
14 14 14 14
1.88 1.60 1.78 1.89
78 67 71 73
41 41 41 41
1.1 1.2 1.2 1.2
70 70 70 80 80
55 58 60 62 65
138 138 138 145 145
38 38 38 38 38
28 28 28 28 28
24 24 24 24 24
M10 M10 M10 M10 M10
14 14 14 14 14
2.93 3.37 3.69 3.14 3.57
106 116 123 101 110
83 83 83 83 83
2.3 2.3 2.3 2.4 2.4
80 80 90 90 90
68 70 70 75 78
145 145 160 160 160
38 38 38 38 38
28 28 28 28 28
24 24 24 24 24
M10 M10 M10 M10 M10
14 14 16 16 16
4.02 4.35 4.09 4.89 5.42
118 124 117 130 139
83 83 83 83 83
2.4 2.4 2.8 2.8 2.8
100 100 100 100 110
78 80 82 85 85
180 180 180 180 190
45 45 45 45 45
33 33 33 33 33
26 26 26 26 26
M12 M12 M12 M12 M12
14 14 14 14 14
5.98 6.37 6.49 7.16 6.18
153 159 158 168 145
145 145 145 145 145
3.8 3.8 3.8 3.8 4.1
110 110 110 120 120
88 90 95 95 100
190 190 190 205 205
45 45 45 45 45
33 33 33 33 33
26 26 26 26 26
M12 M12 M12 M12 M12
14 14 14 16 16
6.8 7.24 8.38 8.25 9.45
154 160 176 173 189
145 145 145 145 145
4.1 4.1 4.1 4.7 4.7
120 140 140 140 160
105 110 115 120 125
205 230 230 230 260
45 50 50 50 50
33 38 38 38 38
26 34 34 34 34
M12 M12 M12 M12 M12
16 22 22 22 26
10.74 12.86 14.44 16.14 17.13
204 233 251 269 274
145 145 145 145 145
4.7 7.4 7.4 7.4 9.2
160 160 160
130 135 140
260 260 260
50 50 50
38 38 38
34 34 34
M12 M12 M12
26 26 26
18.99 20.94 23
292 310 328
145 145 145
9.2 9.2 9.2
