Reliable Price Pneumatic Tires 3 Stage Mast Diesel Forklift Truck 3ton Forklift with Complete Warranty
- Category: >>>
- Supplier: Guangzhou Sunrise Machinery Equipment Co. Ltd.
Share on (60794734401):
Product Overview
Description
Product Name：Cheap Price Pneumatic Tires 3 Stage Mast Diesel Forklift Truck 3ton Hlei Forklift with 3 Years Warranty
Products Description
FORKLIFT SPECIFICATIONS | ||||||||||
No. | Specifications | Unit | FD30 | |||||||
1 | Characteristics | Power | diesel | |||||||
2 | Rated Capacity | kg | 3000 | |||||||
3 | Center of load | mm | 500 | |||||||
4 | Lifting height | mm | 3000 | |||||||
5 | Free lifting height | mm | 145 | |||||||
6 | Forks L×W×H | mm | 1070x125x45 | |||||||
7 | Tilt Forward/Backward | ° | 6.12 | |||||||
8 | Min.turning radius | mm | 2400 | |||||||
9 | Min.ground clearance(Mast) | mm | 110 | |||||||
10 | Overhead guard height | mm | 2138 | |||||||
11 | Front overhang | mm | 943 | |||||||
12 | Perf | Max.traveling speed(loaded) | km/h | 483 | ||||||
Max.traveling speed(loaded) | km/h | 20 | ||||||||
13 | Max.lifting speed(loaded/empty) | mm/s | 470/520 | |||||||
14 | Drawbar pull/Gradeability | kN/% | 18/20 | |||||||
15 | Dimensions | Overall length (without fork) | mm | 2695 | ||||||
16 | Overall width | mm | 1230 | |||||||
17 | Mast lowered height | mm | 2055 | |||||||
18 | Mast extended height | mm | 4256 | |||||||
19 | Chassis | Tire | Front | 28x9-15-12PR | ||||||
20 | Rear | 6.50-10-10PR | ||||||||
21 | Wheelbase | mm | 1700 | |||||||
22 | Tread width | Front/Rear | mm | 1000/970 | ||||||
23 | Curb weight | None-load | kg | 4350 | ||||||
Standard facility for Good performance 3 ton diesel forklift truck :：
Wide view mast. Standard forks. Standard seat. Charging indicator. Load backrest. Reversing lamp. Reversing buzzer. Reverse mirror. Lighting switch. Light guard. Horn. Two pieces of multiway valve. Engine misses device.
Rear combined lamps. Transparency mask of overhead guard. Rib tire. Hour meter. Neutral indicator. Air filter clog warning. Cable parking brake. Lifting and tilting level. Hoist cylinder oil relief valve. Clevis pin. Light. Tilt steering wheel.
Tilt oil channel self-locking valve. Hydraulic power steering. Top intake duct. Hand lever. Water temperature indicator.
Tool box. Foot board rubber pad. Whirlwind type air cleaner. Combination instrument. Hydraulic oil circuit element. Hydraulic oil scale. Oil-pressure warning. Lock switch. Brake. Direction indicator lamp
Forklift Feature：
