4x2 Forland 5 cubic meter water truck

Product Overview

Description

4x2 Forland 5 cubic meter water truck

Ⅰ. The Product Description

A water tanker is a motor vehicle designed to carry water on roads for sprinkling, spraying, planting, watering, washing, rushing, misting, transporting,etc.





The Parameters of 5CBM Water Tanker
Overview
Name	Water Tanker
Dimension(LxWxH)	5990X1960X2380(mm)
Total Mass	8050Kg
Rated Payload	5000Kg
Kerb Weight	3050Kg
Passenger	3
Approach/Departure Angle	19/15
The Parameters of Chassis
Manufacture/Model	Forland
Driving Type	4*2 left/right hand drive
Wheel Base	3300 mm
Gearbox	Six speed lever with five speed forward and one reverse, manual
Front/Rear Track	1506/1466(mm)
Tyre	7.00-16
The Number of Tyre	6+1(spare tyre)
Front/Rear Suspension	1032/1658(mm)
Leaf Spring Number	8/9+5, 6/8+4
The Paremeters of Engine
Manufacturer/Model	Yunei
Rated Power	62hp
Fuel Type	Diesel oil
Displacement/Capacity	3856ml
Emission Standard	Euro3
Cylinder	Straight/4/intercooling
Max. torque	350N.m
Velocity	3200rpm
The Parameters of Tank
Color/LOGO	Customizable
Material	Carbon steel,Stainless Steel,Aluminum Alloy,etc.
Function	Sprinkling,spraying,planting,watering, washing,rushing,misting,transporting,etc.
Volume	5000L
Thickness	5mm
Basic Equipment	Front rusher, rear sprinkler, side sprayer, water gun, outflow valve, fire fighting joint, 2 pcs 3 meters water hoses, etc.
Optional Equipment	Remote control in cab, Honda pump, cannon, alarm light, sluice gate on the sides, crane, atomizing device, LED arrow lights, etc.





We provide all sizes of water trucks and trailers with volumes mainly ranging from 3cbm to 60cbm. The tank materials could be carbon steel,stainless steel,aluminum alloy,etc.



The basic equipment includes front rusher, rear sprinkler, side sprayer, water gun, outflow valve, fire fighting joint, 2 pcs 3 meters water hoses, etc.  The optional equipment includes remote control in cab, Honda pump, cannon, alarm light, sluice gate on the sides, crane, atomizing device, LED arrow lights, etc.



Ⅱ. Packaging&Shipping

We provide Ro-Ro, container and bulk shipping.

Ⅲ. Our Factory&Certificate

Hubei Dali Special Automobile Manufacturing Co,. ltd. is located in the China special automobile industry city-Suizhou, Hubei Province. The company is the first domestic private enterprise entering the special automobile industry, which is also the first pressure tank vehicle manufacturing private enterprise and got the quarantine license from General Administration of Quality Supervision of China. The company has focused on all kinds of special automobile R&D, manufacturing, sales and service. Dali Special is a high-tech enterprise in Hubei province and has passed the certification of ISO9001, ISO16949, GJB9001 and CCC authentication of automobile products.
