BW-280/12 Mud Pump:
BW-280/12 mud pump is a horizontal, triplex, single acting reciprocation piston pump. The pump can choose diesel motor power, It has simple operation, convenient, can achieve close range or remote control. This pump is a compact structure, smooth operation, high output pressure, longer life expectancy, stable performance, goodgeneral and so on.
This pump adopts the car transmission,Can get six different discharge and pressure,Reasonable configuration parameters selection,The construction technology can satisfy different requirements,Mainly used drilling fluid in supply for 2000m about core drilling coal field geology,metallurgy geology,hydrogeololgy,drilling fluid can use mud and water, the coal water etc.
BW-280/12 mud pump is a horizontal, triplex, single acting reciprocation piston pump. The pump can choose diesel motor power, It has simple operation, convenient, can achieve close range or remote control. This pump is a compact structure, smooth operation, high output pressure, longer life expectancy, stable performance, goodgeneral and so on.
This pump adopts the car transmission,Can get six different discharge and pressure,Reasonable configuration parameters selection,The construction technology can satisfy different requirements,Mainly used drilling fluid in supply for 2000m about core drilling coal field geology,metallurgy geology,hydrogeololgy,drilling fluid can use mud and water, the coal water etc.
Technical Parameters
| Model | BW-280/12 | |||||
| Type | Horizontal, triplex, single acting reciprocation piston pump | |||||
| Cylinder bore(mm) | φ85 | |||||
| Stroke(mm) | 110 | |||||
| Pump speed(min-1) | 161 | 132 | 93 | 62 | 36 | 23 |
| Discharge(l/min) | 280 | 225 | 165 | 110 | 65 | 40 |
| Pressure(MPa) | 7 | 8 | 10 | 12 | 12 | 12 |
| Driving Power(Kw) | 45 | |||||
| Suction Pipe Dia.(mm) | φ76 | |||||
| Discharge Pipe Dia.(mm) | φ51 | |||||
| Weight (Kg) | 1500 | |||||
| Dimensions (mm) | 2700x1400x1500 | |||||
BW Series Size Mud Pumps Available:
BW-120, BW-145, BW-150, BW150/1.5, BWZ-150, BW-160, BW160/10, BW-160H, BW-200, BW-250, BW-280/12, BW-280/30, BW300/12, BW-300/12B, BW-300/16, BW-320, BW-350/15, BW-450, BW-450/5, BW-600/10, BW-800/15, BW-1000/12, BW-1500/12, BW-2000/12, BW-2500/16.
Horizontal Directional Drill Series Pumps:
BW-100, BW-150GM, BWF-160/10, BWF-240, BW-250A, BWF-250, BW-320A, BWF-400/10, BWF-600/10.
