Product Overview

Description


Packing & Delivery

Packaging Details : box,or could be packed by customers' requirement

Port : Guangzhou/Shanghai/Ningbo

Lead Time : 15-20days

Product Description

Description:
CVS red copper diaphragm check valve is of a diaphragm self-suction design, which has a red copper tube full hermetic valve body structure with inside filter screen, magnetic and PTFE coated metal diaphragm. Therefore, the check valve self-closing will not be influenced by the angle of installation or the reversal pressure. It enjoys a lot of advantages such as the minimum flow resistance, high flow rate and almost zero leakage in reverse operation.

Application:
CVS red copper diaphragm check valve is used on the exhaust pipe of the compressor to prevent the condensed liquid refrigerant flowing back to the compressor.

Features:

★The brass valve seat, the diaphragm self-suction structure design and the inside filter screen make the produce with both filter and check valve functions.

★The self-closing of the check valve will not be restricted by the angle of installation, neither be influenced by the reversal pressure.

★The higher external sealing performance is ensured by the red copper tube full hermetic valve body structure.

★The universal ODF port is convenient in replacement. ODF port size: 1/4"~3-1/8".

★It has high flow rate and minimum flow resistance.

★Straight-through type product is compact and lightweight with almost zero leafage in reverse operation.

★With PTFE coated metal diaphragm, it is applicable to all types of refrigerants and the applicable medium temperature: -40℃~+130℃


\t
Technical Parameters
\t
Applicable Refrigerants
\t
HCFC, HFC
\t
Applicable Medium Temperature
\t
-40℃~+130℃
\t
Minimum Opening Valve Pressure Differential
\t
△P=0.03MPa
\t
\t
\t
\t
\t
Product Model:
\t
Type
\t
Port Dimension d(in)
\t
Copper Tube OD D(mm)
\t
Max.Working Pressure(MPa)
\t
Liquid Refrigeration Capacity(KW)
\t
Fiter Screen Mesh Number
\t
L(mm)
\t
CVS-6
\t
1/4
\t
Φ22
\t
5.5
\t
6.8
\t
40
\t
102
\t
CVS-10
\t
3/8
\t
Φ22
\t
5.5
\t
14.2
\t
40
\t
102
\t
CVS-12
\t
1/2
\t
Φ28.6
\t
5.2
\t
38.2
\t
40
\t
127
\t
CVS-16
\t
5/8
\t
Φ28.6
\t
5.2
\t
42.6
\t
40
\t
127
\t
CVS-19
\t
3/4
\t
Φ41
\t
4.1
\t
79.7
\t
40
\t
178
\t
CVS-22
\t
7/8
\t
Φ41
\t
4.1
\t
108.5
\t
40
\t
178
\t
CVS-28
\t
1-1/8
\t
Φ54
\t
4
\t
188.5
\t
40
\t
212
\t
CVS-35
\t
1-3/8
\t
Φ54
\t
4
\t
232.8
\t
40
\t
212
\t
CVS-42
\t
1-5/8
\t
Φ79.4
\t
3
\t
397.7
\t
40
\t
265
\t
CVS-54
\t
2-1/8
\t
Φ79.4
\t
3
\t
691.1
\t
40
\t
265
\t
CVS-67
\t
2-5/8
\t
Φ105
\t
3
\t
927.3
\t
40
\t
330
\t
CVS-79
\t
3-1/8
\t
Φ105
\t
3
\t
1262.5
\t
40
\t
330
