Jasu Factory Price One Step Automatic Plastic Bottles Jars Fast Making Machine Injection Stretch Blow Molding Machine Equipment
- Category: >>>
- Supplier: Guangzhou Jasu Precision Machinery Co. Ltd.
Share on (60797694814):
Product Overview
Description
ONE STEP INJECTION STRETCH BLOW MOLDING MACHINE ISB1100A-3
IB1100A-3 Main Specification | Main Devices Brand | ||
Material | PC,PP,PET,TRITAN,PMMA,PS | Servo Motor and Oil Pump | Phase (Italy) and Eckerle (Germany) |
Screw Diameter | 50mm | Sealing Parts | Yuken(Japan), TAIWAN |
Screw L/D Ratio | 20.5:1 | Hydraulic Valve | Yuken(Japan), TAIWAN |
Screw Speed | 0-150 | Air Valve | AirTAC |
Theoretical Injection cavity | 481cm3 | Air Cylinder | AirTAC |
Injection Pressure | 176Mp | Controller (PC) | JASU, TAIWAN |
Max.hydraulic Pressure | 140kg/cm | Photosensor | Carlo,China |
The actual injection quantity | 452g(ps),16Oz | Safety delay | Schneider (ShangHai |
Screw Stroke | 245mm | Servo Motor for Turntable | TECO, Taiwan |
Blow Clamping Force | 150kn | Gear Reducer | SESAME, Taiwan |
Clamp Tonnage | 600kn | Low-voltage components | Joint Venture |
Wheel Diameter | 1100mm | Hydraulic hose | China |
Max.Height Of Bottle | With core:20-220mm | F.R.L | China |
Open Vertical Mode Trip | 570mm | Hydraulic joint | China |
Max.Pump Pressure | 16Mpa | Blowing valve | AirTAC(TaiWan) |
Servo Motor | 22kw | Low-pressure cylinder | AirTAC(TaiWan) |
Electric power | 12.2kw | low-pressure valve | AirTAC(TaiWan) |
Tank volume | 450L | PLC | JASU(TaiWan |
Dimension of Machine | 4.5*1.95*3.6m | Air switch | Schneider(Shanghai) |
Machine Weight | 8.5T | Display screen | JASU(TaiWan) |
Compare with One-step and Two-step:
| Molding | Process | Structure | Manpower/Energy/Space | Product Quality |
| One-step | From preform to product | One machine | Little | Not affect by damp and less pollution; Various kinds of shape |
| Two-step | Injection and blow molding are two separated process | 1.Injection molding machine 2.Preform transiting machine 3.Reheating, stretch and off-moulding machine | More | Easy affect by damp and polluted; Singleness shape
|
FAQ:
Q1: All of your products are made by your self or compacted via purchasing the others?
A1: We have independent technical team who focus on making machines; all the products are made by our technical team.
Q2: What is the ability of your factory?
A2: About blow molding machine, we could produce 30 sets machine per month
Q3: Do you have any technical supports about your products?
A3: We have had long term collaboration with German, and we have a lot of cooperation with a lot of advanced manufacture company on the world.
Q4: Do you have any other service about your products?
A4: We have a lot of experience on making complete “Turn-Key” projects and specifications for our clients. Also we have a fixed service system
Q5: How do you make the quotation for clients?
A5: The price depends on quality and performance but the clients should be satisfied us at first
We have someone who will provde you best solution
