Geology and Mineralogy | rock, gravel, sand, minerals |
Ceramics | porcelain, ceramic sintering, clay, cement |
Chemistry | pesticides, fertilizers, salts, inorganic and organic materials |
Biology | plants, leaves, freeze-dried samples |
Pharmaceuticals | ophthalmological agents, gels, creams, extracts, drugs, pastes, dragees, tablets |
Metallurgy | ores, sinters |
Material technology | pigments, precious materials, new materials, alloys, mechanical alloying and activating |
Analysis preparation | spectroscopy, X-ray fluorescence, X-ray structure analysis, chromatography |
1). Stable running, high efficiency, low noise and non-pollution
2). Dry or wet grinding is available, the machine is suitable for rough and fine grinding,and can be also applied to mixing materials.
3). The machine is self-equipped with pouring device, and has the advantages of separating powder and ball media automatically, it is convenient to output powder.
4). Equipped with safety cover, high purity materials and non-pollution.
5). Anti-abrasion, high efficiency of grinding.
6). Various of liner jars can be selected such as alloyed steel, stainless steel, abrasion-resisting polyurethane, corundum ceramic, zirconia etc. Models of 30-2000L volume are available for customers’ needs.
Various Models | ||||||
Model No. | Tank Volume (L) | Actual Capacity per time (L) | Rotate Speed (rpm) | Power Supply | Feed Size (mm) | Output Granularity Size (mesh) |
YLK-S-30L | 30 | 10.5 | 20~60rpm | 0.75KW/220V | ≤10 | ≥300 |
YLK-S-50L | 50 | 17.5 | 20~50rpm | 1.5KW/220V | ≤10 | ≥300 |
YLK-S-100L | 100 | 35 | 20~45rpm | 2.2KW/380V | ≤20 | ≥300 |
YLK-S-200L | 200 | 70 | 20~40rpm | 4KW/380V | ≤20 | ≥300 |
YLK-S-300L | 300 | 105 | 20~38rpm | 5.5KW/380V | ≤20 | ≥300 |
YLK-S-500L | 500 | 175 | 20~36rpm | 7.5KW/380V | ≤20 | ≥300 |
YLK-S-1000L | 1000 | 350 | 20~34rpm | 11KW/380V | ≤30 | ≥300 |
YLK-S-2000L | 2000 | 700 | 20~34rpm | 22KW/380V | ≤30 | ≥300 |
Available Jars: Carbon Steel,Stainless Steel; Available Liners: Nylon Liner,Alumina Ceramic Liner,PU(polyurethane) Liner,PTFE Liner |
