Solid Carbide PDC Coated Long length 5XD Dream Twist Drill Bits
Solid Carbide PDC Coated Long length 5XD Dream Twist Drill Bits
Solid Carbide PDC Coated Long length 5XD Dream Twist Drill Bits
Solid Carbide PDC Coated Long length 5XD Dream Twist Drill Bits
Solid Carbide PDC Coated Long length 5XD Dream Twist Drill Bits
Solid Carbide PDC Coated Long length 5XD Dream Twist Drill Bits
Solid Carbide PDC Coated Long length 5XD Dream Twist Drill Bits

Solid Carbide PDC Coated Long length 5XD Dream Twist Drill Bits

Share on (60798684691):


Price:

Quantity:


Product Overview

Description



Specifications


Solid carbide drills without coolant hole , 3D
flute dia (mm)
Length of Cut l(mm)
Flute of  Length L2(mm)
Shank dia(mm)
O.A.L (mm)
3.0-3.5
14
20
6
62
3.6-4.7
17
24
6
66
4.8-6.0
20
28
6
66
6.1-7.0
24
34
8
79
7.2-8.0
29
41
8
79
8.1-10
35
47
10
89
10.1-12
40
55
12
102
12.1-14
43
60
14
107
14.1-16
45
65
16
115
16.1-18
51
73
18
123
18.1-20
55
79
20
131
Solid carbide drills without coolant hole , 5D
flute dia (mm)
Length of Cut l(mm)
Flute of  Length L2(mm)
Shank dia(mm)
O.A.L (mm)
3.0-3.7
23
28
6
66
3.8-4.7
29
36
6
74
4.8-6.0
35
44
6
82
6.1-8.0
43
53
8
91
8.1-10
49
61
10
103
10.1-12
56
71
12
118
12.1-14
60
77
14
124
14.1-16
63
83
16
133
16.1-18
71
93
18
143
18.1-20
77
101
20
153


Product Description


1. Tungsten Carbide Mills HRC45 Stainless Steel Processing Twist Drill Bits
2. HRC45 Micro Grain Solid carbide
3. TISIN coating
4. 1mm-25mm / 1/16" to 3/4 "- Metric or Inch
5. DIN 6539 Standard
Products specification
1. Drilling point for 140 degree
2. 5xd
3. Din standard
4. Chemical Composition: 10%Co-Wc 90
5. Raw Material: Super Micro grain with Diameter less than 0.2UM
6. International Industrial Standard: K05-K15, K20-K30, K20-K40
7. Application areas: Machining of cast iron, nonferrous alloy, chill cast iron, hard steel, stainless steel, plastic materials, fiberglass, carbon fiber and other non-metallic.
8. Served industries: Aerospace, Transportation, Medical Equipment, Military Manufacturing, Mold Development, etc.






Detailed Images


1. Surface TIAIN coated
2. Strength2500-4000N/mm2 Controling ModeCNC
3. UsageMetal Chemical Composition6%-12%Co-WC
4. Density14.45-14.90g/cm3
5. Chemical Composition: 10%Co-Wc
6. Raw Material: Super Micro grain with Diameter less than 0.2UM
7. International Industrial Standard: K10, K05-K15, K20-K30, K20-K40
8. Application areas: Machining of cast iron, nonferrous alloy,chill cast iron,hard steel,stainless steel,plastic materials,fiberglass,carbon fiber and other non-metallic.
9. Served industries: Aerospace,Transportation, Medical Equipment,Military Manufacturing,Mold Development,etc.



Product Image




Raw materials




Packing & Delivery




Factory Photo
