High Efficiency Gold Processing Machine , Minerals Extraction Equipment
Xinhai concentrates on providing the Turn-key Solution for Mineral Processing Plant.We have many solutions to process gold. The following is an introduction for Gold CIP,we also have gold CIL,gold heap leaching and gold flotation.Products Description
Gold Extraction Machine——Product Description
【Introduction】:Gold CIP process adsorbs gold from cyaniding pulp by active carbon including 7 steps: leaching pulp preparation,cyaniding leaching, carbon adsorption, gold loaded carbon desorption, pregnant solution electrodeposit, carbon acid regeneration,leaching pulp. Gold CIP system is a useful gold recovery method in mineral processing.
【Application】:There are two kinds of ore suitable for gold CIP system: flotation gold concentrate, amalgamation and gravity tailings; mudded oxidized ore
【Application】:There are two kinds of ore suitable for gold CIP system: flotation gold concentrate, amalgamation and gravity tailings; mudded oxidized ore
Process Description
Gold Extraction Machine——Process Description
Impurity removing of gold CIP process
Before the adsorption of cyaniding pulp, remove the wood chips to avoid it adsorbs the gold and blocks the carbon screen.
Leaching and adsorption of gold CIP process
Adding carbon in the leaching tank; the carbon absorbs gold becoming gold loaded carbon. After adsorption, carbon screen separates
the carbon and pulp.
Desorption electrolysis of gold CIP process
Under high temperature and pressure, gold loaded carbon separates gold mud and carbon in closed system
Smelting of gold CIP process
After simple pickling and impurity removal, the gold ingots are obtained
Desorption electrolysis system with high efficiency, low energy consumption and fast
Before the adsorption of cyaniding pulp, remove the wood chips to avoid it adsorbs the gold and blocks the carbon screen.
Leaching and adsorption of gold CIP process
Adding carbon in the leaching tank; the carbon absorbs gold becoming gold loaded carbon. After adsorption, carbon screen separates
the carbon and pulp.
Desorption electrolysis of gold CIP process
Under high temperature and pressure, gold loaded carbon separates gold mud and carbon in closed system
Smelting of gold CIP process
After simple pickling and impurity removal, the gold ingots are obtained
Desorption electrolysis system with high efficiency, low energy consumption and fast
Process Flow
Related Products
The gold extraction machine mainly include following equipment,You can "click" the picture to know more information!
Gold processing machine: | Crushing Equipment | Grinding Equipment | Leaching Tank | Desorption Electrolysis System |
