DN8 4 20mA Output Digital Loadcell Load Cell Weighing Sensor Indicator/Big 4 LED Display 24VDC/AC220V (IBEST)

Product Overview

Description

DN8 Digital Universal Sensor Indicator/ Big 4 LED Display

(Professional 4-Wire Load Cell Sensor Indicator)



1. Features of IBEST DN8 load cell indicator :

*   Dual line 4 digit display universal indicator ,Upper LED: 20mm high ,Lower LED :9mm high

*   Input :4 Wire load cell indicator

*   With High or Low alarm output ,contact capacity: AC 250V / 3A or DC 30V/3A (resistance load).

*   Isolated analog output: 4~20mA ,analog range adjustable by software.

*   Transmitter power supply: DC 12V / 30mA max.

*   Measuring accuracy: ≤ ±0.5%F.S ± 2 digit (under normal conditions).

*   Product power supply: AC 90~260V 50/60HZ ,power consumption<5A.



*   Superior to be used as weighing indicator : insolated DC 12V/30mA supply; set G.W. and N.W. freely ,clear zero floating ,modulus setting to eleminate deviation of weighing sensor, reset by external buttons.

*  RS485 communication Can link to PC through communcation interface.



2. Ordering code

3. Technical Specification

Power supply	AC 90-250V  50/60HZ (+/- 10%)
Power consumption	≤ 5VA
Accuracy	±0.3%F.S (under normal conditions)
Sampling rate	< 0.3 s/times
Input	4 Wire load cell input
Alarm output	Relay : NO.Contact capacity : AC 250V / 3A or DC 30V / 3A Cosφ=1
Analog output	4~20mA output
Transmitter supply	Isolated DC 12V/30mA or DC 12V/30mA
Insulation strengh	1500V Rms (between terminal points and plastic case) ; 50MΩ/M (500V DC,between the terminal points and plastic case)
Ambient temperature	0~50°C  / 35~85% (RH)



4. Instrument Dimension:
