Rutile Grade TiO2 White Powder Titanium Dioxide Pigment for Polyolefins, Styrenics, Polymer Venator Tioxide Huntsman R FC5

VENATOR ( HUNTSMAN ) TOXIDE® R-FC5 pigment is an alumina surface treated hydrophobic titanium dioxide pigment offering rapid and excellent dispersibility in a large range of polymers in dry processing as well as in liquid plasticizers. TIOXIDE® R-FC5 pigment fine crystal and particle sizes position it in the group of blue undertone plastics grades.

Applications of VENATOR ( HUNTSMAN ) TOXIDE® R-FC5

TIOXIDE® R-FC5 pigment is particularly recommended for use in systems in which fineness of pigment dispersion in the polymer is the top priority: polyolefins, styrenics, engineering polymers, etc. TIOXIDE® R-FC5 pigment permits production of highly pigmented concentrates, such as polyolefin masterbatches. It can also be used in rubber and linoleum. TIOXIDE® R-FC5 pigment enables the manufacture of highly pigmented concentrates, e.g. 70% plasticizer preparations of all widely used liquid plasticizers.

Typical Properties of VENATOR ( HUNTSMAN ) TOXIDE® R-FC5
Titanium Dioxide classification (DIN EN ISO 591-1): --  R2

TiO2 content [%]: --  Minimum 97

Inorganic surface treatment (Compounds based on:): --  AI

Organic surface treatment Hydrophobic: polysiloxane

Color coordinate L* (PVC-P): --  Approx. 97

Color coordinate b* (PVC-P): --  Approx. 3.5

Rel. lightening power (PVC-P): -- Approx. 105

Bluish undertone Rz/Rx (PVC-P): -- Approx. 1.045

Fineness of grind [μm]: --  < 20

Durability Moderately: --  durable

Specific gravity [g/mL]: --  Approx. 4.1

Detailed Images

Packing & Delivery

Package of VENATOR TOXIDE® R-FC5

25 kg Bag, Non-Batch Inclusive
Net Weight: 25 kg
Bags per Pallet: 40
Bag Weight Tolerance: -0.159, +0.159 kg/bag

Container Loading of VENATOR TOXIDE® R-FC5

40 Bags in One Pallet
20 Pallets in One 20" Container
Total Net Weight: 20,000 kgs in one 20" Container
