Product Description




























1. Thermal resistance or thermocouple input and measuring range both can be set freely.


2. Software adjust zero and full scale, temperature measuring of cold-end alone, amplifier constant-zero, display accuracy is better than 0.5%FS.
3. The method of fuzzy theory with the traditional PID make the temperature be controlled quickly and smoothly.
4. The method of advanced PID parameter self-tuning saves a third time as compared with ordinary instrument.
5.  Five Optional output type: Relay output, DC12V voltage output, 4-20mA current output, phase shift /zero-crossing output voltage regulator, analog output.
6. Alarm output: two circuit user-defined alarm output.








































































Model


XMTD-2581 /XMTD-2681 /XMTD-2181/XMTD-2081


Dimensions


72*72*76mm (install size: 68*68mm)


Temperature sensor input


thermocouple: K, J, E ; thermal resistance: Pt100 ;                                analog output: 1-5V(4-20mA),0-5V(0-20mA)                                                  all compatible in one meter


Measuring Range


K(-50-1300/999℃) , J(-50-999℃) , E(-50-800℃),                              Pt100(-50-650℃)


Precision Class


0.5 class(±0.5%F±1); 1.0 class(±1.0%F±1)


Sampling Rate


2 times/sec


Adjustment  Method


intelligent PID adjustment (P ,PI, PD ,PID)


Main Control Output


DC12V voltage output to control SSR to regulate the temperature


Type differ by Alarm Function


XMTD-2581 (one way upper limit bias alarm default 10degree)


XMTD-2681 ( one way lower limit absolute value default 100degree )


XMTD-2181 ( one way upper limit alarm and one way lower limit alarm )


XMTD-2081 ( no alarm)


Output Voltage


DC12V , Max. Load Current: 60mA


Working Power


transformer : 220VAC±10% 50/60Hz; 100-240V (could be customized)


Power Consumption


< 3VA


Ambient Temperature


temperature -10°C~50°C; humidity <85% non-corrosive occasion





product recommendati










Company Information







Certifications


.png





Packaging & Shipping







FAQ


1. Q: Can you provide OEM service?


    A: Yes, we can.


2. Q: What's the MOQ?


    A: For testing purpose, 1pc is ok.


3. Q: Can you provide trade assurance service?


    A: Yes, we are member of the Alibaba trade assurance scheme.


4. Q: What's the lead time?


    A: General lead time is 15 days after payment.


5. Q: What's your waranty?


    A: We provide 12 months warranty against manufacturing defective.
