Environmentally friendly mini biomass steam industrial boiler prices

Share on (60800702200):


Price:

Quantity:


Product Overview

Description


Environmentally friendly mini biomass steam industrial boiler prices





2






Product Description





1. In the design structure, compared with the traditional boiler furnace space, and very reasonable secondary air arrangement,





2. The boiler has the characteristics of high thermal efficiency, no pollution, no emission, compact structure, etc. It is an alternative to electric, combustion and gas steam boilers.


3. The furnace body is generally made of a special seamless tube for boilers. Because the generator has high pressure and temperature during normal operation, the safety protection system makes it safe, reliable and efficient in long-term operation. The safety valve consists of a strong copper alloy, check valve and exhaust valve for three-stage protection.





Environmentally friendly mini biomass steam industrial boiler prices









Mini biomass steam industrial boiler core advantages:





1. Rapid steam generation in five minutes, the thermal efficiency can reach more than 90%, the pressure is stable, and the running cost is low.
2. Low noise, low concentration of smoke and dust, no black smoke, fully in line with national first-class regional emission standards, environmentally friendly and reliable
3. Fully automatic control system with automatic high and low water level protection, saving manpower.




The mini biomass steam industrial boiler production process:Environmentally friendly mini biomass steam industrial boiler prices





click on and send us inquiry





product parameters


Mini biomass steam industrial boiler technical parameters:















































Fuel Cost analysis(Take 100 kg per hour as an example)



Equipment selection



Steam volume



Energy consumption



Unit Price



Operating costs



Electrothermal steam boiler



100kg



72 kw/h



0.08 USD/kw



10.91 USD



Fuel steam boiler



100kg



7 kg/h



0.53 USD/kg



7.42 USD



Gas steam boiler



100kg



8 m³/h natural gas



0.34 USD/m³



5.45 USD



Biomass steam boiler



100kg



20 kg/h wood pellet



0.08 USD/kg



3.03 USD
































































































Biomass steam boiler technical



Rated evaporation



Rated pressure



Rated steam tempe


rature



Feed water temper


ature



Design thermal efficiency



Water capacity



Steam outlet



water intake



Drain valve



Dimensions



Shipping weight



Full load biomass consumption



L



W



H



Kg/h



Mpa







%



L



DN



DN



DN



mm



mm



mm



T



Kg/h



300



0.7



170℃



20℃



87%



28



25



15



25



2000



1400



2700



1.35



49.3



500



0.7



170℃



20℃



93%



29



32



15



25



2500



1800



2500



4.1



76.8



1000



0.7



170℃



20℃



92%



29



32



15



25



3000



2300



2500



6



153.5









 The mini biomass steam industrial boiler application area:





Environmentally friendly mini biomass steam industrial boiler prices


Application field description:


1.For food industry: food factory, beverage factory, bakery, high temperature milk sterilization, steamed soy milk, steamed steamed buns.








2.For pharmaceutical industry: hospital disinfection, hospital canteen, hospital bath, pharmaceutical equipment heating, cooking medicine.





3.For biological equipment industry:  sterilizer, school laboratory, thermal test


 our engineering case:


Environmentally friendly mini biomass steam industrial boiler prices








Related Products




Company Information


1.Henan Swet Boiler Co.Ltd was established in 1954 ,We have continued to provide customers with more than 60 years of quality service, known as the king of China's boiler.


2.It's the national designated A-class boiler and D1,D2 class pressure vessel manufacturing key enterprises and has passed ISO9001 international quality management certification system certification.It holds level 1 boiler installation permit. National special equipment manufacturing license ,National specialequipment installation remould maintenance permits and so on.Environmentally friendly mini biomass steam industrial boiler prices














Our Factory





Our main products include circular fluidized bed (CFB) boilers, gas boilers, coal boilers, biomass boilers, oil boilers, power plant boilers, energy efficient boilers, slag boilers, efficient boilers, electric boilers, high pressure boilers, fully automatic Control of boilers, wood vapors biomass boilers, chain grate, condensing boilers, natural gas steam boilers, water pipe boilers, fire pipe boilers, all artificial intelligence boilers, biomass steam generators, refractory materials, boiler accessories and so on.





Environmentally friendly mini biomass steam industrial boiler pricesEnvironmentally friendly mini biomass steam industrial boiler prices





Customer Access





Environmentally friendly mini biomass steam industrial boiler prices





Packaging & Shipping








Environmentally friendly mini biomass steam industrial boiler prices








FAQ





Q: Can I get guarantee of products?


A: Yes, every product is 1 year quality warranty under customer correct using the products.


Q: Do you have any Certificate?


A: Yes. Each of our boiler has China GB  and ISO9001certificate


Q: How can I pay you?


A: T/T is very well used.We also accept other ways, depending on the circumstances


Q: What about the production?


A: Produce time is 30 days


Q: What about the maintenance?


     A: I will offer you the timely maintenance way sheet after installation of the boiler mainly parts.








    Q:How to install a boiler?


      A:Our boiler provides completed installation drawing and manual, or send engineer abroad for installation guidance.


    Q:How many years is the boiler’s life?


      A:The boiler is designed for 20years life.


    Q:How to choose a boiler model?


      A:Confirm the type (steam or hot water), capacity, pressure (or output temperature need) and fuel(coal, biomass, gas or oil) of the boiler, we will suggest a suitable model based on your usage


    Q:How is the warranty term?


      A:If any problems caused for quality during the warranty period, the Seller will repair or replace the broken parts for free, if the problem caused from the client’s side, the Seller will help supply the spare part at lowest cost.
