Cheap price 150J 300J metal materials charpy pendulum Impact tester

150J 300J metal materials charpy pendulum Impact tester is used to test the impact resistance performance of the metal materials under dynamic load, being an indispensable testing instrument in metallurgy and machine manufacturing units and is also a necessary testing instrument for the research of new materials in research institutions. The series model is the mostly widely used impact testing machine at the current market .

Technical parameters:

1. Impact energy: 300J, 150J

2. Pendulum force value (impact constant):

0—300J M=160.7695N.m

0-150J M=80.3848N.m

3. Swing and rising angle: 150.

4. Distance from the center of the pendulum to the strike center: 750mm,

5. Impact speed: 5.2m/s

6. Sample support span: 40mm

7. Radius of the sample holder end arc: R1-1.5mm

8. Impact knife arc radius: R2-2.5mm

9. The angle between the two inclined faces of the impact knife: 30°±1°

10. Impact knife thickness: 16mm

11. Specimen size: (10±0.1)*(10±0.1)*(55±0.1)mm

12. Weight: about 450Kg

13. Dimensions: 2124 × 600 × 1340mm

Power supply: three-phase four-wire system 50Hz 380V
