JIMI AT3 3G Mini Car GPS Tracker 5400mAh Battery 5 years Ultra long Strong Magnet IPX5 Dust and Waterproof Tamper Alert
- Category: GPS Tracker >>>
- Supplier: Shenzhen Jimi Iot Co. Ltd.
Share on (60800966232):
Product Overview
Description
HARDWARE
AT3 3G GPS Asset Tracker
The AT3 is an all-in-one, rugged device featuring a long-lasting battery, tracking hardware and a powerful magnetic mount. With GPS for location tracking and GSM + WCDMA for data communication, the AT3 supports fast and accurate real-time tracking. With a battery that can provide 2.5 years of tracking (at 1 location per day), the AT3 is an ideal self-contained hardware solution for long term deployments.
Features:
●WCDMA & GSM network support
3G network for outstanding coverage
●Tamper alert
●Tamper alert
Once the device is disassembled, you will get informed immediately
●5400mAh disposable battery
●5400mAh disposable battery
Built-in 5400mAh battery ensure sufficient power supply
●2.5 years standby Time (1 position per day)
●2.5 years standby Time (1 position per day)
5400mAh high power lithium battery ensure sufficient power supply
●IPX5 water resistance
●IPX5 water resistance
Water-resistant case to ensure stable operation in tough environment
●Strong magnet mount
Strong magnetic cover allowing for flexible mouting on vehicles or assets
●Strong magnet mount
Strong magnetic cover allowing for flexible mouting on vehicles or assets
Specifications:
GSM Specification | ||
GSM frequency | GSM850/GSM900:33±3dBm WCDMA 850/900/1900/2100MHz | |
Communication system | GSM | |
GPRS | Class 12, TCP/IP | |
Receive sensitivity | Class II RBER2%(-102dBm) | |
Memory | 32+32Mb | |
Phase error | RMSPE<5,PPE<20 | |
Max output | GSM850/GSM900:33±3dBm GSM1800/GSM1900:30±3Bm | |
Max frequency error | ±0.1ppm | |
GPS Specification | ||
GPS chipset | MTK high sensitivity chip | |
Frequency | GPS L1, 1575.42MHz | |
GPS channel | 32 | |
Location accuracy | <10 meters | |
Tracking sensitivity | -162dBm | |
Acquisition sensitivity | -148dBm | |
TTFF (open sky) | Avg. hot start≤1sec Avg. cold start≤35sec | |
Function & Package | ||
Switch | 1 for base falling detection | |
LED Indicator | Re: status | |
Working Voltage/current | 7-18VDC | |
Operating temperature | -20℃～ 70℃ | |
GSM/GPS antenna | Built-in quad-band GSM antenna, GPS dual-mode antenna | |
Tracking hour | 80 hours ( GPS always ON) | |
Battery | 5400mAh / 3.6V lithium battery | |
Dimension | 93.0 x 58.0x 22.0mm | |
Weight | 160g | |
Appearance:
Certificates:
CE
SOFTWARE
Tracksolid
