Compressed Air System air compressor air purifier hepa filters 5μm 0.5μm 0.01μm
SPECIFICATIONS FOR compressor air purifier hepa filters
Model
Thread Size
Capacity(CBM/MIN)
Weight(KGS)
Dimension(A*B*C)
ZAF0020
G1/2" OR 3/4"
0.57
1.5
95*220*197
ZAF0045
G3/4
1.3
1.5
95*220*197
ZAF0070
G3/4"
22
2
95*280*257
ZAF0100
G3/4"
2.8
2
95*280*257
ZAF0125
G1 1/2 OR G1
3.5
3.2
125*320*290
ZAF0180
G1 1/2 OR G1
5.1
3.2
125*320*290
ZAF0265
G1 1/2
7.5
4
125*400*370
ZAF0370
G1 1/2
10.5
4
125*400*370
ZAF0515
G2"
14.6
8.5
170*520*478
ZAF0745
G2"
21.1
10
170*700*658
ZAF0900
G2 1/2 OR G3
25.5
20
200*995*938
ZAF1060
G2 1/2 OR G3
30
22
200*995*938
ZAKF air compressor advantages
1. we are air compressor factory, quality and deliver time is under control, compessor colour, logo, voltage, pressure , motor can customized.
2. Monthly output capacity is 1500set machine, Quality has been recognized by the market
3. All English Compressor data and manual .
4. 24hours After-sale service.
5. our own factory, visit factory on anytime you want.
6. Top quality spare parts A. Air filter: Donaldson air filter, Dust removal effect 99.99%, work good under bad enviroment B. Oil filter: Oil filter with glass fiber filter material with spin on type, the filtration effect is 20% higher than the conventional filter element C. Air / oil separator: Large-capacity design, high-quality air and oil separation, three time oil and gas separation, oil content below 2ppm D. Thermostat valve: Prevent the temperature of the lubricant from being too high make oil emulsification or too low make oil carbon deposit, Guaranteed long-term use of lubricating oil and good sealing performance
7. energy saving and environmental protection , especially the Inverter machine / Two stage machine, 50HP for example: When the air demand becomes small, the air compressor frequency is automatically reduced, the power sequentially reduced 50HP to 40HP to 30HP,20hp.... When the air gas demand becomes larger, the frequency of the air compressor automatically increases, the power is sequentially increased 30HP to 40HP to 50HP...
8. Inverter machine is good at Power saving, and Saving electricity bills, 37kw /50HP for example (energy saving 20% -25% ) 37kw * 20% * 22hours one day * 312 days one year * us$ 0.15 kw/h (electricity cost) = us$ 7619.00 / year our inverter compressor machine can save us$ 7619.00 each year for you of the electricity cost
FAQ
Q1: Are you manufacturer or trade company? A1:We are manufacturer.
Q2: What the exactly address of your factory? A2: Our company is located in 3F, building B, No.168, Dezheng East Road, Chang'An Town, Dongguan City, Guangdong Province, China
Q3: Warranty terms of your machine? A3: One year warranty for the machine and 24hours technical support according to your needs.
Q4: How about payment terms? A4: 30% TT deposit + 70% TT before shipment, 50% TT deposit + 50% LC balance.
Q5: How long will you take to arrange production? A5: If in stock, we will shipping it in 3 workdays; if no stock or have some special requests, like change the color or change 380V/50HZ to other electricity, we will delivery it in 15workdays.
Q6: Can you accept OEM orders? A6: Yes, with professional design team, OEM orders are highly welcome.
