12V/24V/36V/48V 30A MPPT Solar Charge Controller
- Category: >>>
- Supplier: Shenzhen Melin Sunergy Co. Ltd.
Share on (60802185015):
Product Overview
Description
12V/24V/36V/48V 30A MPPT Solar Charge Controller
| Product Model | ML4830 |
| System voltage | 12V, 24V, 36V, 48V auto |
| Battery voltage | 9V~70V |
| Max solar panel voltage | <150V |
| Max input power | 400W/12V 800W/24V 1200W/36V 1600W/48V |
| Max capacity load capacity | 10000uF |
| No-load loss | 0.7W-1.2W |
| Charging current | 30A |
| Discharging current | 20A |
| Conversion efficiency | ≤98% |
| MPPT tracking efficiency | >99% |
| Operating temperature | -35°C~+45°C |
| Temperature compensation factor | -3mv/°C/2V(default) |
| Waterproof | IP32 |
| Communication method | RS232 |
| Altitude | ≤3000m |
| Product dimensions | 266x182x81mm |
| Weight | 2.3kg |
