Dongfeng 6X4 12 cubic meters Cement mixer truck, cement mixer price ,mobile cement mixer

Product Overview

Description

Dongfeng 6X4  12 cubic meters Cement mixer truck, cement mixer price ,mobile cement mixer



Capacity: 12 Cubic meters

Engine Power: 341HP

Drive Type: 6x4

Specialization: As per your requirement accurately!









Truck specification:



Subject	Dongfeng 6X4  12cubic meters Cement mixer truck
Dimensions	9800X2500X3998
Chassis Model	DFH1258AX1V
Gross Vehicle Weight(kgs)		25000
Rated loading capacity(kgs)		10370
Curb Weight (kgs)		14500
Engine	Engine brand	DONGFENG
	Model	ISL9.5-340E51A / 341 HP
	Type	In-line, 6-cylinder, water cooling ,4-stroke, supercharging, intermediate cooler, high pressure common rail
	Displacement Volume(ml)	9460
	Net Power(kw)	Min.  251  kw at rated RPM
	Emission Standard	EOUR 3
Clutch System	Single Plate, Dry friction
Steering System	Power Steering	Left hand driving
Transmission System	manually operated, 10 forwards and 2 reverse
Brake System	Service Brake	front brake pad
	Park Brake	automatically air-cut brake,
Suspension System (front & rear)	Semi-elliptical leaf spring with telescopic shock absorber (both front & rear)
Tire Specification	10 pcs of 11.00R20Wire tire pls spare wheel
Cabin	Driver’s cabin of 3 persons (including driver)with the windshield, ABS, Air- condition, adjustable headlight.





The body Structure:



Material of Tank	The tank is made of alloy-steel and carbon steel Q345, the tank body is six mm thick and the head is eight mm thick.
Hydraulic System	REXROTH	Reduction drive	PMP(Italian Brand)/ ZF(German brand)
Radiator	KaiTong	Water System	500L water pot, Air pressure water supply
Feeding speed	M3/min≥ 3	Unloading speed	M3/min≥ 2
Discharge reside rate	%< 0.5	Operation method	Left and right sides and cab three-way operation
Unloading range	180° up and down height adjustment	Safety equipment	Adding a leak receiving device
Delivery time	30 days after receiving the payment
Warranty	12 months, from the date of supply.
