Brass Flanged Swing Check Valve RF or FF
Brass Flanged Swing Check Valve RF or FF
Brass Flanged Swing Check Valve RF or FF
Brass Flanged Swing Check Valve RF or FF
Brass Flanged Swing Check Valve RF or FF
Brass Flanged Swing Check Valve RF or FF
Brass Flanged Swing Check Valve RF or FF

Brass Flanged Swing Check Valve RF or FF

Share on (60802780847):


Price:$19.50 - $20.00

Quantity:


Product Overview

Description



Technical Parameters


Technical Parameters & Characteristics












































































Product DescriptionBrass Flanged Swing Check Valve
Nominal Diameter1/2"~8"(DN15~DN200)
Operating Temperature -20 Deg. C~120 Deg. C(the range of service temperature may vary for different materials)
Operating PressureClass150, PN10, PN16, 200WOG, 400WOG, 600WOG
Main MaterialsBrass
Seat StructureMetal Seated
GasketPTFE
Design standardASME B16.34, ISO STD
Structural lengthANSI and Manufacture Standard
Connect EndsRF, FF
Ends StandardASME B16.5, EN 1092, BS 4504, BS 10
Test standardISO5208
Application Cold/hot Water, Oil, Gas
Other Features 1Easy of Maintenances
Other Features 2Renewable Disc
Other Features 3Stock is available
Other Features 4Union Bonnet, Bolted Bonnet
