HPF IC Chip LED Tube Driver Tube Light Power Supply 30 36W

Product Overview

Description

HPF IC Chip LED Tube Driver Tube Light Power Supply 30-36W

MODEL		HG-PF2227B
OUTPUT	DC VOLTAGE	36-84V
	CONSTANT CURRENT REGION	400mA
	RATED CURRENT	400mA
	RATED POWER	30-36W
	RIPPLE & NOISE(Max.)	8.6Vp-p
	VOLTAGE RANGE	DC36-84V
INPUT	VOLTAGE RANGE	AC100-260V
	FREQUENCY RANGE	50/60Hz
	POWER FACTOR(Typ.)	0.967
	TOTAL HARMONIC DISTORTION(THD)	<25%
	EFFICIENCY(Typ.)	92.3%
	AC CURRENT	<0.3A
PROTECTION	SHORT CIRCUIT	Hiccup mode, recovers automatically after fault condition is removed.
	OVER LOAD	Protection type: Shut down o/p voltage, re-power on to recover
Function	DIMMABLE FUNCTION	Non
EMC	EMC EMISSION	Compliance to EN55015
OTHERS	DIMENSION	L150*W15*H10mm
	PACKING	18g
	WORKING TEMP.	-30~+70℃
	WORKING HUMIDITY	20~95% RH non-condensing
