HY WDS2DVSE 0 60m/s Ultrasonic Anemometer plug and play for Davis Vanatge Pro 2 weather station

Share on (60803585058):


Price:

Quantity:


Product Overview

Description


Product Description

 Compatible With Davis Vantage Pro2 Equipment



HY-WDS2DVSE Ultrasonic Anemometer is completely powered by solar panel come with it. This model is customized to be completely compatible with Davis Vantage Pro2 series weather station, can be directly connected to Davis ISS via RJ11 port.

Thanks to ultrasonic technology, cost-effective HY-WDS2DVSE with significant advantages (Robust, No moving part & inertia) can obviously optimize performance of Davis’ weather station, make it free from maintenance(wind part).

The "Plug & Play" WDS2DVSE connects directly to a pulse or potentiometer input. Maintenance-free plug & play ultrasound WDS2DVSE wind sensor upgrade for Davis weather stations, replaces anenometer models: # 7911, #7913, #7914, #6410.

Technical specification

Signal Output

wind speed

pulse signal

wind direction

potentiometer signal

Connection

RJ11

Wind Speed

Range

0 - 60m/s

Accuracy

±2%

Resolution

0.01m/s(0.2 knots)

Threshold

0.01m/s

Wind Direction

Range

0  - 359°

Accuracy

±3°

Resolution

Heating Function

Optional

Power Supply

Self-powered by Solar Panel & 2 pcs rechargeable 18650 lithium battery

Environmental

Protection Class

IP65

Operating Temperature

-40 to +60

Operating Humidity

0 to 100% RH

CE

Approved

Mechanical

WDS2DVSE

Material Engineering ABS shell, Size:Φ144×163mm,
Weight:ABS:0.38kg



Solar Panel

Size: 25 cm*18cm Weight:2kg.





Installation Sketch













Packing List

1. HY-WDS2DVSE anemometer

2. Solar panel with power manage module

3. 13 meters RJ11 cable

4. Conjunction plate and clamps for installation

5. Installation mast



Our Services



Price, Package, Service

1, Price : EXW, FOB, CIF
2, Payment: 100% T/T in advance, west union or paypal .
3, Packing : standard export packing , including instructions
4, Leading time :  5-8 working days after payment.
5, OEM avaliable
6, Shipment: Express (FedEx, DHL, UPS & TNT) or forwarder (by sea, air)
7. One year free repair for quality warranty
