Codonics Horizon G1 Medical Printer Film Multi Media Imager Medical Printer
- Category: >>>
- Supplier: Guangzhou Zetop Medical Co. Ltd.
Share on (60803824883):
Product Overview
Description
Product Description
Codonics Horizon G1 Medical Printer Film Multi-Media Imager Medical Printer
Overview:
The Horizon G1 is anintelligent, desktop dryimager that produces diagnostic quality medical films plus grayscale paper prints if you choose the optional paper feature. The imager is compatible with many industry standard protocols including DICOM and Windows network printing. Horizonalso features direct modality connection, with up to 24 simultaneous DICOM connections. Highspeed image processing, networking and spooling arestandard.
Specifications
| Print Technology | Direct thermal ( dry, daylightsafe operation) |
| Spatial Resolution | 320 DPI (12.6pixels/mm) |
| Throughput | Up to 100 films per hour |
| Time To Operate | 5 minutes (readyto print from “off” ) |
| Grayscale Contrast Resolution | 12 bits (4096) |
| Media Inputs | One supply cassette, 80 -100 sheets |
| Media Outputs | One receive tray, 50- sheet capacity |
| Media Sizes | 8” x 10”,14” x 17” (blue and clear), 11” x 14”( blue) DirectVista® Film Optional A, A4 , 14” x 17” DirectVista Grayscale Paper |
| Dmax | >3.10 with DirectVista Film |
| Archival | >20 years with DirectVista Film, under ANSI extended-term storage conditions |
| Media Supply | All media is pre-packaged and factory sealed |
| Interfaces | Standard:10/100/1,000 Base-T Ethernet (RJ-45 ), Serial Console |
| Network Protocols | Standard: 24 DICOM connections, FTP, LPR Optional: Windows network printing |
| Image Formats | Standard: DICOM,TIFF, GIF, PCX, BMP, PGM, PNG, PPM, XWD, JPEG,SGI (RGB), Sun Raster, Targa Optional: PostScript™ compatibility |
| Image Quality | Manual calibration |
| ImageControl | Gamma, Contrast,Polarity, Rotation, Scaling, Antialiasing |
| Sheet Control | Density Adjustment (Dmax),Look-Up Tables ( LUT), Image Warnings,Captions, Sheet |
| Memory | 1GB |
