High Pressure 6000psi CL2500 Monoflange DBB Valve
- Category: >>>
- Supplier: Henze Valves Corporation
Share on (60804490406):
Product Overview
Description
Technical Parameters
| Product Description | Monoflange DBB Valve |
| Nominal Diameter | 1/2"~4"(DN6~DN100) |
| Operating Temperature | -196 Deg. C~350 Deg. C(the range of service temperature may vary for different materials) |
| Operating Pressure | Class150~Class2500, up to 6000PSI/WOG |
| Main Materials | A105, LF2, F304, F316, F304L, F316L, SAF2205, SAF2507 |
| Seat/Seal Materials | PTFE, RPTFE, Devlon, PEEK Or Metal Seated |
| Gasket/Packing | PTFE Or Graphite |
| Design standard | ASME B16.34, ISO STD |
| Structural length | ANSI and Manufacture Standard |
| Connect Ends | FlangeXFNPT, FlangeXFBSP |
| Ends Standard | ASME B16.5, ASME B1.20.1, ISO STD |
| Test standard | ISO5208, API598 |
| Operation method | Handwheel |
| Application | Cold/hot Water, Oil, Gas |
| Other Features 1 | One Piece Body |
| Other Features 2 | Small Operating Torque |
| Other Features 3 | Renewable Packing |
| Other Features 4 | Stock is available |
| Other Features 5 | Reduce Bore |
Machining
Machining
Aseembling
Aseembling
Testing
Testing
Finished Products
Finished Products
Packing and Shipping
Packing and Shipping
Service
Service
