IP67 Waterproof led flood light 20w -4000w Real 160 lm per watt | Main Feature - Premium Precise Optical Lens System, 4-10 times brighter than conventional light
- Modular Design, Easier mounting and maintenance
- Direct Heat Path Technology, 2-5 times better stability
- Anti-Glare System, high quality light delivery.
- IP66 waterproof,and support to customize IP68 for underwater lighting
- Open structure for improving heat dissipation.
- Varies beam angle: 10°, 25°, 40°, 60°, 90° ,120°
- Photocell,sensor,dimmable is available with costup
- 480V & 380V,24V/48V available
- 5 Years Warranty!
Technical Parameter ITEM | IP67 Waterproof LED Lamp | ITEM NO | LS-FLN-L series | LS-FLN series | Power | 20W - 4000W | 20W - 4000W | Light Source | Bridgelux /Cree | Bridgelux /Cree | Input Voltage | 90-265VAC 50-60HZ | 90-265VAC 50-60HZ | Power Factor (PF) | ≥0.95 | ≥0.95 | Power Efficiency | ≥90% | ≥90% | Color Index(CRI) | Ra>80 | Ra>80 | Light Angle | 10°, 25°, 40°, 60°, 90°,120° | 10°,25°,40°,60°,90°,120° | Color Temp: | 2700-3500K 4000-4500k
5000-6500K
6500-7500K | 2700-3500K 4000-4500k
5000-6500K
6500-7500K | LED Luminous Efficiency | 140lm / Watt | 160lm / Watt | Luminous Flux (Typ.) | Power x 140lm | Power x 160lm | Life Span | ≥80000 hours | ≥80000 hours | Work Temperature: | - 40 ° C ~ 65 ° C | - 40 ° C ~ 65 ° C | Storage Temperature: | - 40 ° C ~ 80 ° C | - 40 ° C ~ 80 ° C | Working Humidity | 10 % ~ 90 % RH | 10 % ~ 90 % RH | IP Rating | IP67 | IP67 | Light Attenuation(80000h) | 30% | 30% |
|
Flood light Lsleds flood light LS-FLN series is available from 20w to 4000w with lumen efficiency up to REAL 160 lm/w
Available wattage | Model | Power/watt | Lumen/LM | Replacement/
Metal Halide | Lamp Holder | | LS-FLN100-LITE | 100 | 160000 | 400W | U bracket | | LS-FLN150-LITE | 150 | 24000 | 600W | U bracket | | LS-FLN200-LITE | 200 | 32000 | 800W | U bracket | | LS-FLN240-LITE | 240 | 38400 | 800W | U bracket | | LS-FLN300-LITE | 300 | 48000 | 1000W | U bracket | | LS-FLN360-LITE | 360 | 57600 | 1200W | U bracket | | LS-FLN400-LITE | 400 | 64000 | 1400W | U bracket | | LS-FLN480-LITE | 480 | 76800 | 1400W | U bracket | | LS-FLN500-LITE | 500 | 80000 | 1500W | U bracket | | LS-FLN540-LITE | 540 | 86400 | 1700W | U bracket | | LS-FLN720-LITE | 720 | 115200 | 2000W | U bracket | | LS-FLN840-LITE | 840 | 134400 | 2200W | U bracket | | LS-FLN900-LITE | 900 | 144000 | 2400W | U bracket | | LS-FLN1000-LITE | 1000 | 160000 | 2500W | U bracket | | LS-FLN1500-LITE | 1500 | 240000 | 4000W | U bracket | | LS-FLN2000-LITE | 2000 | 320000 | 6000W | U bracket | | LS-FLN4000-LITE | 4000 | 640000 | 12000W | U bracket |
Best materials Lsleds use the best quality materials in our products to make sure the quality,including meanwell & inventronics driver,bridgelux chip,aluminum housing,304/316 stainless steel bracket,and silicon rubber cable etc.
Products Testing All of Lsleds led light fixtures will pass a circle of testing to make sure it can survive in the harese environment with the great brightness, including IES testing,salt water spray testing,vibration testing, high/low temperature test,waterproof testing and 120 hours aging testing
Packing - For Power <=300watt ---it will be packed with Polyfoam inside and reinforce carton box outside
- For Power>300w --- it will be packed with Strong polyfoam inside and wooden box outside
Shipping - Air Express (DHL / UPS / EMS / FEDEX) home delivery for sample or small quantity
- Air Transport for small quantity
- Ocean shipping for mass
Trade Terms - Payment term: T/T 30% deposit after order confirmed, the balance before shipping
- Lead time : normally in 10-20 working days after deposit received.
- Shipping port: shenzhen,China.
- Discounts : We offer discount for big quantity.
- All the prices are based on EXW price,not included the freight and tax
Lsleds led flood light is widely use for sport,tennis court,football field,baseball field,cricket field ,Hockey area,Horse racing,Golf field,apron,harbor,contruction site,mobile lighting tower,parking lot ,high mast, marine lighting
Common Replacement Case | Item | Lsleds Lamp | Original Lamp | Original Lamp for 1000lux | | Total number | 1000w x 184pcs | 1500w x 112pcs | 1500w x 224pcs | | Unit Lamp Power | 1000w + 50w(95% power efficiency) =1050w | 1500w + 350w(80% power efficiency) =1850w | 1500w + 350w(80% power efficiency) =1850w | | Ground illumination level | 1000-1200lux | 500-600lux | 1000-1200lux | | Total Power | 193KW | 207KW | 414KW |
Lsleds light advantage  Lsleds professional in provide high quality led high power lights over 13 years with hundreds of projects experience,and we have different series flood lights to suit for different market and different projects need, also,with our professional enginner team support,we are able to provide customize service,such as customize IP68 LED light, customize light for high temperature 90 ℃(190°F),Customize 15000k-20000k for aquairum lighting,customize CRI98 for film lighting etc In a word,we are able to recommend the right products to your special projects ,not one products to cover all the application.  Certification Lsleds all light fixture have passed TUV,ETL,CE certificates and complied RoHS restriction.
Trading Partners Lsleds is the partner of Ericsson over 6 years, and our ED lights have been used in BBC TV broadcasting , Hollywood film and stadiums for Sochi Winter Olympics Bundesliga and Italy Serie A.  Trade shows Lsleds attend the famous Fair all over the world every year to promote our lights, and we warmly welcome our potential partners to visit our booth in the lighting show and also our factory in shenzhen. - Middle East Lighting fair (Dubai),
- Interlight light Moscow (Russian)
- Strategies in light ( USA)
- Hongkong international lighting fair (China)
- Frankfurt lighting fair (Germany)
Our service - Reply you inquiry in 24 working hours
- Customized design is available,OEM and ODM are welcomed
- Delivery the goods to our customer all over the world with speed and precision
- Offer customer the lowest price with high quality LED light
- Providing the best solutions to our customers
Thank you for browsing! If any questions, please do not hesitate to contact us. |
