Product Overview
Description
Product Description
Each element of phased array probes can be independently controlled by the electric signals. In connection with the PA equipment, it can transmit ultrasonic beams from different angles for dynamic focusing and real-time scanning.
Models & Features
For much more models no. please do contact me!
| Models | Casing No. | Stl.Rfr-Angl. | Rmd Scan Rng. | Ptd. Angl. |
| SC5-N0L | C5 | 0°LW | -30°-30° | 0° |
| SC5-N45L | C5 | 45°LW | 30°-60° | 16° |
| SC5-N60L | C5 | 60°LW | 45°-70° | 20° |
| SC5-N70L | C5 | 70°LW | 50°-80° | 22° |
| SC5-N45S | C5 | 45°SW | 30°-60° | 31° |
| SC5-N55S | C5 | 55°SW | 30°-70° | 36° |
| SC5-N60S | C5 | 60°SW | 45°-70° | 39° |
| SC5-N70S | C5 | 70°SW | 50°-80° | 43° |
| SC7-N0L | C7 | 0°LW | -30°-30° | 0° |
| SC7-N45L | C7 | 45°LW | 30°-60° | 16° |
| SC7-N60L | C7 | 60°LW | 45°-70° | 20° |
| SC7-N70L | C7 | 70°LW | 50°-80° | 22° |
| SC7-N45S | C7 | 45°SW | 30°-60° | 31° |
| SC7-N55S | C7 | 55°SW | 30°-70° | 36° |
| SC7-N60S | C7 | 60°SW | 45°-70° | 39° |
| SC7-N70S | C7 | 70°SW | 50°-80° | 43° |
| SC10-N0L | C10 | 0°LW | -30°-30° | 0° |
| SC10-N45L | C10 | 45°LW | 30°-60° | 16° |
| SC10-N60L | C10 | 60°LW | 45°-70° | 20° |
| SC10-N70L | C10 | 70°LW | 50°-80° | 22° |
| SC10-N45S | C10 | 45°SW | 30°-60° | 31° |
| SC10-N55S | C10 | 55°SW | 30°-70° | 36° |
| SC10-N60S | C10 | 60°SW | 45°-70° | 39° |
| SC10-N70S | C10 | 70°SW | 50°-80° | 43° |
