Introduction & Application:


The Meters is analog display instrument, moving coil structure, which mainly measure Frequency in transmission & distributing power system.

Standard: Comply with GB/T7676-98


Product Description

Technical Data:

1. Usage: Marine type;
2. Indicating Angle: G(Wide Angle), 240°-270°;
3. Measurement: For frequency
3. Measuring Range:45-55Hz, 55-65Hz, 45-65Hz,350-450Hz
4. Connection Way: 100V, 220V,380V,400V,440V,690V;
5. Mounting: Vertical installation;
6. Dimension(mm): 96*96,72*72;

Technical Parameters
\t
Item
\t
Technical Data
\t
International Standard
\t
Technical Standard
\t
GB/T7676-1998
\t
IEC60092-50
\t
Environment Standard
\t
GB8355-1987
\t
IEC92-504-74
\t
Safety Standard
\t
GB4793-20
\t
IEC61010
\t
Working Temperature
\t
-40℃-65℃
\t
\t
Temperature Influence
\t
-13-33℃, 100% comply with accuracy class
\t
Indicating Angle
\t
240-270° (Synchroscope meter:360°)
\t
Color of Shell
\t
Black/white , board frame , terminal plate : Black
\t
Color of Dial Plate
\t
Black/white, other colors are available on requests
\t
Mounting
\t
Vertical mounting
\t
\t

Dimension
\t
110*110mm,  80*80mm
\t
\t
96*96mm, 72*72mm, 48*48mm
\t
\t
Overshoot
\t
Less than 20% when scale reaches to 2/3
\t
Insulation Withstand
\t
Circuit & shell: AC2600V/1 minute(Water area)
\t
Vibration Resistance
\t
24.5m/s2
\t
\t
Impact Resistance
\t
147m/s2
\t
\t
Material
\t
Shell/terminal board: ABS;  Cover: Transparent Glass
