High quality competitive price moulding silicone rubber mould making silicone medical liquid silicone with good after service

Share on (60806653903):


Price:

Quantity:


Product Overview

Description


Company Information

 Shenzhen Zhihua Chemical Co., Ltd.(DC SILICONE) waswas established in 2008,is a science and technology Company which is concentrating on production, R&D, and sales of Chemical products, especially silicone rubber. We are praised as the leading professional manufacturer of Mould Making Silicone Rubber,Addition Silicone Rubber,Life Casting Silicone Rubber,Electronic Potting Compound,Pad Printing Silicone Rubber,and so on.we are welcome to all the customers come to visit our factory and have a fruitful bussiness relationship.



moulding silicone rubber

Product Description

100A:2B Mixed ratio RTV-2 liquid silicone rubber for concrete mould



Description of 100A:2B Mixed ratio RTV-2 liquid silicone rubber for concrete mould

DC-C35 RTV-2 Mold Making Silicone Rubber is a kind of room temperature vulcanized silicone rubber in condensation type. It’s generally named as two part silicone rubber, Part A is a flowable liquid silicone, Part B is the curing agent (Tin catalyst) . Its mainly used for mold making.

moulding silicone rubber





Typical Applications of 100A:2B Mixed ratio RTV-2 liquid silicone rubber for concrete mould

DC-C35 RTV-2 Mold Making Silicone Rubber is used for making molds of concrete stone, GRC, gypsum decoration, plaster ornaments, fiberglass products, polyester decoration, unsaturated resin crafts, polyresin crafts, polyurethane, bronze, wax, candle, and similar products.



Technical Parameters of 100A:2B Mixed ratio RTV-2 liquid silicone rubber for concrete mould



Model

Color

Mixing ratio (%)

Pot life (mins,

under 25℃)

Curing time



Hardness  ( Shore A )

Tensile-

strength  (MPa)

Tear-

strength (kN/m)

Viscosity

(After A/B mixed ,mPa.s)

Shrinkage

rate (%)

Elongation

(%)

DC-C35

White



100:2

30-40

(3-5hrs under 25℃);

(20-30 mins under 60℃)

35±2



>4.8





>24





25000±5000



<0.25%

 > 500%



SHELF LIFE:

12 months when stored under 25°C in original unopened packages.



Packaging & Shipping

25KG/drum vacuum packing for part A +1kg/ bottle catalyst for part B;9/18drums/pallet;

200KG/drum packing for part A +1kg/ bottle catalyst for part B; 1//2/4drums/pallet;

Our Services

Techinical Support

Normally, different silicone should be choosed according to different product's features,for example :

- For products size (within 20cm),
with intricate disigns, soft silicone is suitable, such as 10-20 shore A.

- For products size (20cm-80cm),
with intricate designs, 20-25 shore A is suitable.
with simple designs, 25-30 shore A is suitable.

- For products size (80cm-150cm),
with intricate designs, 25 shore A is suitable.
with simple designs, 30-35 shore A is suitable.

- For products size (more than 150cm),
with intricate designs, 25-28 shore a A is suitable.
with simple designs, 35-40 shore A is suitable.





Characteristics

*Good operability, easy to demold

*Moderate hardness

*High tensile and tear strength

*Cure at room temperature

*Good flexibility

*High duplication times





FAQ

FAQs

Why did the clients choose our DC Silicone:

1.Free Sample

2.Silicone Performance Test

3.Technical Support

4.More than 10 years experience of silicone rubber producing.

5.Relatet products purching assistance

6.China visiting reception

7.Factory visiting Reception

8.New market developing

9.New products research and development

10.Engineers Site Instruction



11.DC Silicone Quality Control with Strict Management

Why could the silicone mold be reused only for a few times?

Maybe you will confuse about this question for years. Here we share you some following reasons:



a. Adding too much silicone oil into silicone rubber. Silicone oil is an additive which will destroy the molecular weight of silicone rubber and reduce the tension and tear strength.



b. Adding too much catalyst into the silicone rubber when you make the molds. For the condensation cure(tin catalyst) silicone rubber. we suggest you add no more than 2% of catalyst. If you 1add too much catalyst, the operation time will be too fast to operate ,which will also reduce the tension and tear strength.



c. Using the silicon rubber with a high hardness to make molds for small sized products with delicate and intricate designs and the silicon rubber with a low hardness to makes molds for large sized products with simple designs.

Why does the silicone mold get burnt out?

The silicone mold get burnt out because you have left out the important notes when using unsaturated resin materials to produce your products. The unsaturated resin produces great heat when added the curing agent. So you must demould the product within 3 minutes to avoid this problem.



Our DC silicone rubber has add a special material which can resistant high temperature to make the resin molds. Help our customer avoid this problem.

Why does the silicone mould appear to be dry outside but wet inside?

Because molding silicone rubber is a kind of condensation silicone rubber, which get solidified after absorbing moisture from the air. In order to provide a significant shelf-life for the silicon rubber, we will dry out the water in the silicon rubber.



Solution: Add 0.05% water into the silicon rubber and Stir over a low speed briefly when you use it.

Why is the tear strength of the silicone mold weak?

There has three resons:



Firstly:In order to reduce the viscosity of silicone rubber and pursue a good quality, you may add a lot of silicone oil into the silicon rubber when making molds. In fact, it might have just the opposite effect. The tension and the tear strength will be reduced badly with the addition of silicon oil. And the silicon molds will be in a weak and flimsy manner.



Sencondly:you may add too much catalyst into the silicone rubber,we suggest customers add catalyst no more than 5%,2%will be perfect.



Thirdly:you may use the silicone mold too early after it finished.we suggest the customer begin using the molds after 24 hours. whatsmore,it will be better if you can make a outmold to protect the silicone mold.

Why is the silicon mold oily?

The molding silicone rubber itself doesn’t contain any oil, so it won’t be oily. If the mold is oily, it may be because of two resons:



1.you add the compound silicone oil( the compound of silicon oil and white oil). The white oil is not silicon oil but a kind of petrochemicals.



2.Your supplier add to much silicone oil when they producing silicone rubber or reducing the hardness of silicone rubber.
