Separating the fiberglass skins with a foam core delivers greater strength properties than those of the skins alone. The fiberglass skins offer high strength-to-weight ratio, thermal and electrical conductivity, high tensile strength, low density, low weight, low thermal expansion and excellent fatigue resistance.
Main Features:
Combines multiple materials to create a unique material
Lighter structures
Enhanced mechanical properties
High strength
High stiffness
Design flexibility
Thermal insulation
Very durable
Detailed Image
Skin and Core Options for Insulated Sandwich Panels:
1. The skin material of our sandwich panels are fiberglass sheet and there are several options for you:
l Fiberglass Embossed Sheet;
l Fiberglass Anti-slip Sheet;
l Fiberglass Flat Sheet;
l Fiberglass Gelcoated Sheet.
2. The core materials could be
l XPS;
l PU;
l PP honeycomb;
l plywood.
Size and Specifications:
We have press machine, automatic glue sprayer and CNC cutting machine. Our press machine is 3.2*17 meters. We can produce 10,000Sq.M per month.
All panels are made to order
l Length from 500mm to 17000mm
l Width from 500mm to 3200mm
l Thickness from 10mm to 200mm(thickness of FRP skin can be 1-4mm)
l Color of FRP Skin can be available in (RAL Color Standard)
l Surface of FRP Skin can be high glossy or mat
Mass Product
Anti-Slip Sandwich Panels:
Types of Cores
Types of Core of Insulated Panels:
ITEM
FRP XPS Sandwich Panel
Core Material
XPS, Extrude Polystyrene
Fiberglass Sheet Skin
1-3MM
Core
10-100MM
Width
≤3200MM
Length
≤17000MM
ITEM
FRP PP Honeycomb Panel
Core Material
PP Honeycomb
Fiberglass Sheet Skin
1-3MM
Core
5-100MM
Width
Max 3200MM
Length
Max 17000MM
ITEM
FRP PU Sandwich Panel
Core Material
PU Foam, Polyurethane Foam
Fiberglass Sheet Skin
1-3MM
Core
10-100MM
Width
Max 3200MM
Length
Max 17000MM
ITEM
FRP Plywood Sandwich Panel
Core Material
Plywood panel
Fiberglass Sheet Skin
1-3MM
Core
3-20MM
Width
Max 3200MM
Length
Max 17000MM
Packaging & Shipping
Application
>> Refrigerator Van & Truck Body >> Sentry box & Mobile Toilets >> Caravan & RV Panel >> Compartment & Partition Wall >> Cattle Sheep Shed & Dog Kennel
Why Choose Us
Main Advantages of Our Company:
1. 20-YEAR FRP Sheet making machines manufacturer in China Has the latest production machines and production technology, thus ensure you get the best FRP products.
2. We have two production lines, one for the width less than 1500MM and the other for the width less than 3200MM. And the annual production capacity is more than 3,000,000SQ.M.
3. With ISO 9001:2005 Quality Management System Certificate approved, we have the strict quality control system from the raw material to the finished products.
Quality Control System:
Raw Material
Choose Quality Supplier, Test it before Entering the Warehouse
Mould
Confirm the Size of Mould before production and Ensure the precision of the Design
Experienced Workers
Every Part has different workers to operate
Production Machines
Adjust the Temperature into the Appropriate Value and the Thickness and Speed
Finished Product
Test it before Entering the Warehouse and UN-qualified Product not Sold
Our Production Line:
Our Office and Workshop:
Our Samples Cabinet:
Our Exhibition:
Contact Us
Welcome to Contact us for More Insulated Panels Solutions!
