Микроскоп для тестирования спермы, быстрый тест спермы, устройство для обнаружения спермы

Viewing Head

Trinocular Head for Video Camera      (C Mount)

Eyepiece

Wide Field Eyepiece WF10×,P16 ×

Objective

Achromatic Objective 10×,20×,40×(S),100×(S, Oil)

Nosepiece

Quadruple Nosepiece

Stage

Double Layer Mechanical Stage 140×140mm/ 75×50mm

Focusing

Coaxial Coarse & Fine Adjustment, Moving Range 28mm, Fine Division 0.002mm

Condenser

Abbe NA 1.25 with Iris Diaphragm & Filter

Illumination

S-LED Illumination,Brightness Ajustable

Plan-concave Mirror

Items

specification

Effective Pixels

3 Million

Chip size

1/2"

Pixel size

3.2μm×3.2μm

Resolution and frame rate

Resolution

Frame rate

2048×1536

12FPS

1920×1080(ROI)

18FPS

1024×768(ROI)

40FPS

1024×768(2x2BIN)

33FPS

640×480(ROI)

84FPS

Any resolution ROI

Scanning method

Progressive scan/continuous output

Shutter type

Electronic shutter shutter

Exposure time

47μs -3s

Effective gain

1 - 8x

Spectral response

380 - 650nm

A/D conversion

8bit

Image Cache

32Mb

Trigger mode

Soft trigger

Exposure function

Manual Exposure / Auto Exposure / Area Exposure

White balance

Auto white balance / One-touch white balance / White area balance

Image format

TIF,BMP,JPG,RAW

Software interface

DirectShow / TWAIN

Software development

Support SDK development

operating system

Windows XP 32bit;Windows 7/8/10 32/64bit

Data interface

USB2.0 B interface,480Mb/s

Camera interface

C interface

power supply

USB 5V

working environment

Working temperature:0 - 50℃;

working Humidity:10% - 90%RH(non-condensing)

physical dimension

Ø76mm × 48.7mm
