Manufacturer Direct Supply Composite Bearing

Suitable for grease or oil lubrication and all kinds of movement, good load capacity, robust and insensible to dirt.

Wrapped composite sliding bearing steel / POM - with lubrication pockets
TECHNISCHE DATEN POM-MET
Wrapped composite sliding bearing
Tin-plated steel / acetal resin (POM)
DIN 1494 / ISO 3547
Low-maintenance
With lubrication pockets
Flanged sliding bearings on request

Max Move Load Capacity                                 250 N/mm2

Max Sliding Speed                                            dry 2.5 m/s

Max PV Value Limit                                           2.8 N/mm ·m/s

Friction coecient                                                0.05~0.20μ

Tensile Strength                                                >750 N/mm2

Thermal conductivity                                        50W(m·k)-1
Coecient of thermal expansion                        11×10-6·K-1

Hardness                                                           > 270 HB

Working Temperature                                        - 60 ~ + 120 ℃

Initial pre-lubrication at assembly is strongly recommended

Q: Are you trading company or manufacturer ?

A: We are  manufacturer.

Q: How long is your delivery time?

A: Generally it is 2-5 days if the goods are in stock. or it is 7-30 days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples ? is it free or extra?

A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q: What is your terms of payment ?

A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment. We also accept payment by L/C,D/A,D/P,and so on.
If you have another question, pls feel free to contact us as below:
