Soil reinforcement woven driveway geotextile fabric

Product Overview

Description

Geotextiles include a variety of synthetic polymer materials that are specially fabricated to be used in geotechnical, geoenvironmental, hydraulic and transportation engineering applications. It is convenient to identify the primary function of a geotextile as being one of: separation, filtration, drainage, reinforcement, fluid/gas containment, or erosion control. In some cases the geosynthetic may serve dual functions.

Mechanical Properties	Test Method	Minimum Average (English)	Minimum Average (Metric)
Mass/Unit	ASTM D-5261	9 oz/yd²	305 g/m²
Wide Width Tensile Strength (MD x CD)	ASTM D-4595	3220 x 3450 Ibs/ft	48.5 x 39 kN/m
Grab Tensile Strength (MD x CD)	ASTM D-4632	445 x 320 Ibs	1980 x 1423 N
Grab Tensile Elongation	ASTM D-4632	26 x 20 %	26 x 20 %
Trapezoidal Tear	ASTM D-4533	195 x 165 Ibs	867 x 734 N
CBR Puncture	ASTM D-6241	1200 Ibs	5338 N
Apparent Opening Size(AOS)	ASTM D-4751	40 US Std.Sieve	0.425 mm
Permittivity	ASTM D-4491	0.9 sec-1	0.9 sec-1
Water Flow Rate	ASTM D-4491	70 gal/min/ft²	2852 L/min/m²
UV Resistance (% retained after 500 hours)	ASTM D-4355	90 %	90 %



A: Are you manufacturer?

B: Yes,ae are factory.



A: What's the leading time?

B: Usually 15-25 days.



A: What's your payment term?

B: T/T,L/C,WestUnion and some other convinient payment way.



A: How can I visit your factory?

B: Fly to Ningbo Airpot,We'll send driver to pick you up.
