42 inch oem free standing android advertising player digital signage r
Sepcification of Network advertising player
Main function
Operation System
embedded linux operation system
Supports streaming playback
Support multicast, on demand, rtsp, mms stream real time
Support local download and play
Receive media content by network and store in local to loop, spots, broadcast regularly, gasket Play ect.
Support split screen
Support 1 video area, 5 test area,5 scrolling text, 1 logo area, 1 group date time week area, 1 weather forecast area.
Free split screen, display different media content in different area
OSD support
Support 32bit OSD,can display in any position,support mixture of Video, textand picture,can add picture and text on video,
Support fully transparent,opaque,translucent and other effects, the overall stack no more than 5 layers.
Data format of play
Video format
MPEG-1, MPEG-2,WMV9,AVI(3.11),XVID,H264,Video Capabilities reach D1,720P,1080I,1080P mainstream video formats
Audio format
1. MPEG-1 Layers I,II,III2.0
2. MPEG-4 AAC-LC 5.1
3. MPEG-4 HE-AAC 5.1
4. MPEG-4 BSAC 2.0
5. WAV
6. 24-bit linear PCM 7.1
Picture format
BMP,JPEG,PNG,GIF ect.
Base interface
USB2.0 interface
1pc,Motherboard reserved 1pc PH2.0 USB2.0 socket
Ethernet port
1 10M/100M adaptive Ethernet, RJ-45 interface,
WIFI
built in wireless network card modules WIFI,support 802.11b/g,external 3G module
LVDS output
1way lvds output
Video output
1way VGA output,use PH2.0 socket
1way CVBS output,use PH2.0 socket
Audio output
1way amplifier output,use PH2.0 socket
infrared input
1pc,use PH2.0 socket
other
N/A
Additional function
RTC Real Time Clock support
Reading time data through the microcontroller
Support regular open, shut down
Centralize setting by management system
Watchdog reset support
Using MCU internal watchdog, abnormal automatic recovery
Internal, external IR input
Support DMB-specific remote control (remote control optional)
Board power supply and current indicators
Power input
AC175V~AC260V,50~60Hz
Power
<12W
Working environment
Working temperature
0°C~40°C
Working humidity
10%~90%,
Storage temperature
-40°C~70°C
FAQ
1. Q: Are you a plant or trading company? A:We are a lcd advertising player,digital signage,lcd video wall plant, lcd touch screen. We integrate R&D team, manufacture,quality control team, sale and after-sale service.
2. Q: Where is your plant located? How can I visit there? A:Our factory is located in Shenzhen, GuangDong Province, China. About 15 minutes by car from Shenzhen airport we pick you up there. All our clients from home or abroad are warmly welcome to visit us!
3. Q: For the first order, can we place a advertising player, lcd touch screen kiosk sample order?
A: Yes,of course, when you have our lcd digital signgae, lcd advertising player, lcd video wall samples in hands, you will know more if it is worth to move forward!
4. Q: About the quality control, how will our plant guarantee it?
A:The quality is always our priority.We have Total Quality Management System to control quality. We have our own professional engineer with many years’ experience. Our factory has gained FCC, CE, RoHS etc for our lcd video wall, digital signage, lcd advertising player
5. Q: What is the delivery time of lcd advertising player, digital signage, lcd video wall?
A:For the lcd advertising player, digital signage, lcd video wall in stock, for customized samples and large quantities order, the delivery time is 20-30 days.
6.Q:What is the price of lcd video wall, digital signage, lcd advertising player? And do you provide customization, OEM or ODM service?
A:Our price is depend on the functions, sizes, designs, quantities, applications etc, please send the inquiry and tell us more about your requirements and project then enable us to quote the price accordingly. We have structure engineer team which can provide customization, OEM or ODM service.
7.Q: What is your after-sale service? A: Best service provided for our customers not only pre-sale services but whole life of the goods.
-Warranty period:one year for whole machine. We will help solve it on line via Team Viewer with our engineer.
-How to deal with warranty: If damaged by non-artificial,the buyer should pay the freight when sending the defect parts to the seller,and the seller should pay the freight when sending the replacements or repaired parts to the buyer.
8. Q: What is your MOQ for lcd advertising player, digital signage, lcd video wall?
A: MOQ:1pc. Any quantity is acceptable for your order. And the price is negotiable for large quantity.
