Разъем для аккумулятора электромобиля 30 А
- Category: Connectors >>>
- Supplier: Shenzhen,Green,Power,Technology,Co.,Ltd.
Share on:
Product Overview
Description
Contact barrel wire size | 20-10AWG 0.75-5.3mm² | ||||||
AVG contact resistance | <500 | ||||||
Contact material | Silver plated copper | ||||||
Voltage rating | 600V | ||||||
Rated current | 15-45A | ||||||
Feature | makes assembly quick and easy | ||||||
system | Flat wiping contact system | ||||||
Color | Colored modular housings | ||||||
Application | Electric vehicles;Medical equipment;Power supply;Electric equipment; | ||||||
MQQ | 100 | ||||||
Maximum wire insulation diameter | 0.175inches 4.45mm | ||||||
Insulation withstanding test voltage | 2200v | ||||||
Contact retention force | 25lbf | ||||||
Avg.connection/disconnect | 3-5ibf | ||||||
Operating temperature range | -20°to105° -4°to221° | ||||||
Flammability rating of housing material | UL94-VO | ||||||
