Hot sale Lab Spray Atomizer dryer with Build in Air Compressor, Peristaltic Pump and Glass Chambers
- Category: >>>
- Supplier: Zhengzhou Tainuo Film Materials Co. Ltd.
Share on (60810432170):
Product Overview
Description
Labo Spray Atomizer with Build-in Air Compressor, Peristaltic Pump and Glass Chambers
Product Description
TN-USP-6000 is laboratory spray dryer that generates fine particles by evaporating the atomized liquid spray and been collected through the cyclone separating process. It is suitable for synthesizing heat sensitive materials for a board range of applications such as Nanotechnology, Catalysts, Fuel cells, and Batteries.
Specification
System Features | Dual channel spray nozzle with anti-clogging function prevents the nozzle from being clogged during the spray process Transparent receiving tank, drying chamber and cyclone separator for easy process monitoring Borosilicate glass chamber resists strong acid/alkali and high temperature The use of quick clamps allows easy components removal and cleaning The built-in air compressor is quiet (50dB) and clean (oil-mist free). Built-in PID temperature controller for accurate Inlet/outlet air temperature control User-friendly touch screen enables easy adjustment of temperature, air flow & pressure, pumping speed and anti-clogging interval Solvent feeding via peristaltic pump, rate is adjustable |
Input Voltage & Power | 208~240VAC, 3000W |
Spray Nozzle (Atomizer) | Compress gas assist spray nozzle disperses spray liquid into fine droplets which are subsequently dried in the chamber Dual channel design allows you mix and spray two kinds of solution at the same time Anti-clogging nozzle, auto anti-clogging interval adjustable Co-current downward spray Atomized particle sizes range from 10 - 50 um Spray Nozzle Size is 0.7mm dia. |
Cyclon Material Collector | Material collection efficiency can be as high as 80%. |
Temperature Control | Inlet air: 30 ℃ ~300℃ Outlet air: 30 ℃ ~140℃ PID temperature controller with ±1℃ accuracy |
Drying Time | 1~1.5S |
Drying Air | 35m^3 /h, Pressure: 5~8 bar |
Peristaltic Pump | Solvent is fed by peristaltic pump Feeding rate adjustable: 30~2200ml/h |
Evaporation Capability | 1500ml/h ~ 2000ml/h |
Certification | CE Certified |
Packaging & Shipping
Our Services
1.We are a manufacturer so that we have the punctual delivery time.
2.One sales representative serves you from inquiry to products shipped out.Communicate directly and conveniently.
3.Professional R&D team.
4.Strict QC.
5.Smooth shipping.
6.Rich experience. We do OEM services.Our customers are all over the world like USA, UK, Russia, Korea, Southeast
Asia, etc. so that we are quite experienced.
7.Certificate: All our products are CE approval.
8.Fast reply: Our team will respond your requests within 8-working-hour
Company Information
Zhengzhou TAINUO Film Materials Co., Ltd is mainly engaged in the research and development, design, manufacturing and sales of equipment used in scientific researches. Independence and innovation is the company's tenet.Our main products include: tube furnace, muffle furnace, plasma cleaner, vacuum furnace, atmosphere furnace,CVD system and customized lab equipment.Welcome you come to visit us.
