Product Overview
Description
Thermocouple’s long-time stability and service life will be up to outside protection tube. Thermocouple shielded by silicon
nitride thermocouple sheath will quickly react to temperature due to its good thermal conductivity and thinner wall thickness.
Silicon nitride thermocouple protection tube is for continuous temperature measurement and protect thermocouple without erosion.
nitride thermocouple sheath will quickly react to temperature due to its good thermal conductivity and thinner wall thickness.
Silicon nitride thermocouple protection tube is for continuous temperature measurement and protect thermocouple without erosion.
Physical and chemical index
Types | GPSN | RSSN |
Density | >3.2g/cm3 | >2.4g/cm3 |
Si3N4 content | >92% | >92% |
Flexural strength | >600Mpa | >200Mpa |
Compressive strength | >1500Mpa | |
Thermal conductivity(W/mk) | >22 | >14 |
Porosity | 0 | <15% |
Thermal expansion coeff.(RT-1000℃) | 3.2 | 2.8 |
Max temperature In air | 1400℃ | 1400℃ |
Hardness(HRA) | >92 | >85 |
Features
1, Moulding: Cold isostatic pressing(CIP)
2, Sintering: GPSN/RSSN
3, High strength and good compactness
4, Low thermal expansion coefficient
5, Excellent thermal shock resistance
6, No wetting by molten aluminum and non-ferrous metal
7, Good corrosion resistance
2, Sintering: GPSN/RSSN
3, High strength and good compactness
4, Low thermal expansion coefficient
5, Excellent thermal shock resistance
6, No wetting by molten aluminum and non-ferrous metal
7, Good corrosion resistance
Recommended Sizes
OD(mm) | ID(mm) | Length(mm) | ||
16 | 8 | 300-600 | ||
22 | 12 | 300-800 | ||
28 | 16 | 300-1200 | ||
30 | 18 | 300-1000 | ||
45 | 25 | 300-1000 | ||
We can also produce other sizes according to your drawing. | ||||
