SMT reflow soldering machine Large 8 zone hot air double chain rail reflow oven with industrial computer 8820

Product Overview

Description

SMT reflow soldering machine Large 8 zone hot air double chain rail reflow oven with industrial computer 8820

reflow oven,reflow solder,reflow,reflow soldering oven,smt reflow oven,t960 reflow oven,8 zones reflow oven,

Product name: 8 zone Large reflow soldering oven

Product features:

1 Use of imported heating components, temperature uniformity, high efficiency thermal compensation for CSP, BGA component soldering;
2 Dedicated wind turbine design, ventilation volume, wind speed and stability;
Independent of the temperature zone using forced circulation, independent PID control, the upper and lower independent heating, so the furnace chamber temperature accuracy, uniformity, heat capacity:
3 Warming up quickly, from room temperature to operating temperature < = 30 minutes;
4 Imports of high-quality stable high-temperature high-speed motor transport wind, vibration, noise;
5 Furnace dual cylinder (linear actuators) lifting device, safe and reliable;
6 Chain, the transport network with synchronous constant speed, the use of high frequency accuracy;
7 Special high-quality aluminum rail design, the deformation is small, the chain automatic refueling device;
8 UPS power protection, to ensure normal power output after the PCB board without damage;
9 Powerful software, online monitoring of PCB board temperature, and to keep the data curve analysis, storage and printing;
10 Industrial control PC and PLC using MODBUS protocol communication, stable, put an end to the phenomenon of death;
11 Automatic monitoring, display work state, can be amended at any time parameters;
12 Special patented furnace design, good insulation, low power consumption of the industry;
13 High-temperature deformation patent rails, three screw-width-modulated synchronization structure in parallel to effectively ensure the rail, to prevent the out board, card board the occurrence of no-clean, easy to adjust. Capable of automatic and manual-width-modulated operation.
Standard chain constant parallel transport chain synchronization network can process single-sided, double-sided PCB board, an optional dual-rail transportation system.
14 Auto-width-modulated system uses closed-loop PID control, according to the input parameters automatically transferred to the computer needs of the width, accuracy up to 0.2mm.
15 The temperature zone due to modular design, hot wire the motor and heating maintenance and repair easy.

16 Forced air-cooled centrifugal blower system and rosin automatic recovery system.



Product parameters:

Heating area number	up and down 8 hot air + 2 Cooling zone
Heating zone length	3140 mm
PCB maximum width	480 mm
Transport direction	Left to right
transport wind way	All hot air
solder paste type	Lead-free solder/ordinary solder
Suitable for element types	BGA, CSP, single/double panel, etc
Conveyor belt mesh belt	880 + 20 mm height
Transmission	network transmission
The conveyor belt speed	0-2000mm/min
power supply	380v  5 line 3 phase 50/60 hz
Start the power	36 kw
Normal work power	7 kw
The heating time	about 15 minutes
The temperature control range	at room temperature to 350 ℃
Temperature control	PC+ PLC PID control + SSR drive
The temperature control accuracy	+ / - 1 ℃
Abnormal alarm	temperature anomalies alarm
Exterior size (length * width * height)	4800 * 1450 * 1200mm
The machine weighs	2000 kg





Large Reflow soldering machine guide rail 8 zone with PC control
