FY26D Hydraulic Highway Guardrail sheet post PileDriver for sale

Product Overview

Description

FY26D Hydraulic Highway Guardrail sheet post Pile Driver for sale



No.	Specifications	Unit	HX23D	HX26D	HX36D
1	Hydraulic hammer model		Yc230	Yc260	Yc360
2	Drill rod diameter	mm	68	75	85
3	Engineer power	kw	31
4	Hydraulic system pressure	mpa	16-20	16-20	16-20
5	The hydraulic system flow rate	ml/r	63-80	63-80	63-80
6	Nitrogen gas pressure range	Mpa	1±0.1	1.7±0.1	1.7±0.1
7	Hydraulic hammer impact frequency	bpm	500-900	400-800	400-800
8	Hydraulic hammer work flow	l/min	40-70	50-90	50-90
9	Working pressure of hydraulic hammer	Mpa	9-11	11-14	12-15
10	Working stroke of hydraulic hammer	mm	450-2800	450-2800	450-2800
11	Piling efficiency	mm/min	2100	2400	2700
12	Net weight	kg	about 2000	about 2100	about 2200
13	Steel post diameter	mm	90mm-500mm
14	Maximum ramming depth	mm	2000
15	Maximum post length	mm	2600
16	Drilling diameter	mm	120,150,160,180,200
17	Drilling depth	mm	1700
18	Maximum traction speed	km/h	≤30
19	Traveling Speed	km/h	8-12
20	Hydraulic tank volume	L	80
21	Dimension(L*W*H)	mm	2600*2250*2500(folded)*3700
