Product Overview
Description
1000W CMH Ballast DE Fixture for Greenhouse 220v/380v/400v/415v/480v
Key Featues of 1000W DE Digital Ballast
- 120V/208V/220V/230V/240V/277V sensing input, 50/60Hz
- Easy installation, low profile, saving the space
- High standard components made by Japanese and Germany. E.g.: Nippon Chemi-con capacitors, high capability Infineon,IXYS(Germany)/Fairchild(USA) MOSFETS to bear large amperes, produce less heat, and offer reliability and performance
- Soft start and Random Start
- Microchip Inside for precise control
- Constantly output power when the voltage is fluctuating
- Super High Frequency Sine Wave, fully compatible with DE 1000W HPS/MH lamps
- Multi-protections: Open/Short circuit protection, High/Low voltage protection, Thermal protection, Hot-start protection
- Prolong lifetime of lamp at least 10%
- Energy saving up to 30%-50% compared with MAGNETIC BALLASTS
- Running 10%-15% than other digital electronic ballasts in the market
- Lower EMI/IF compared with other electronic ballasts
- 0.99 Power Factor, and less than 10% Total Harmonic Distortion
- 3 years factory warranty for ballast, 1 year warranty for reflector
- UL, cUL, CE certificates
- 6FT input power cord
- Remote Control by 0-10V controller Optional
Performance Description | ||
Model | HLB-1000SW-120-277V | |
Rated Power | 1000W | |
Input | Voltage Range | 90Vac-305Vac |
Rated Voltage | 120/208/220/230/240/277Vac | |
Current | 8.6A@120V | 4.1A@240V | 3.8A@277v | |
Frequency | 50~60Hz | |
Power | 1060W±5% | |
Power Factor | ≥0.99 | |
THD | <10% | |
Output | Frequency Type | Super High Frequency Sine Wave |
Frequency | >130k Hz | |
Power | 1000W±5% | |
Current Crest Factor | <1.5 | |
Open Circuit Voltage | <300V | |
Ignition Voltage | 3.5~5kV | |
Dimming Function | 600W-630W-825W-1000W-1150W-AUTO | |
Required Lamp Voltage | 200-250V | |
Efficiency(@240Vac) | >93% | |
Protection | Short Circuit | Yes |
Open Circuit | Yes | |
Ignition Failure | Yes | |
End of Lamp Life(EOL) | Yes | |
Overheated | Yes | |
Soft-start | Yes | |
Over Voltage | Yes | |
Lamp | Lamp Type | 1000W DE HPS/MH/CMH lamps |
Lamp Power | 1000W | |
Lamp Voltage | 200~250V | |
Distance to Ballast | <15m(50FT) | |
Reflector | Light Reflection | >95% |
Replaceable | Yes | |
Light Distribution | By Request | |
Materials | Die Casting Arm(ADC12), Reflector(Italian VEGA 95), Screws(Stainless Steel 304) | |
Lamp Holder | DE Socket, PEEK material(bear 572 oF), silicon connection line(bear 392 oF) | |
Physical Description | ||
Dimension(L*W*H) mm | 680x260x160 | |
Net Weight | 6.6kg(cord included) | |
Ventilation | No | |
Waterproof Grade | IP30 | |
Working Humidity | 10%~90% | |
Operating Temperature Range | -30℃~+50℃ | |
Max Case Temperature | <90℃ | |
Internal Temperature Rise | <30℃ | |
Certificate and Standard | ||
Certificate | CE, UL, cUL | |
Safety Regulation | IEC 61347 | |
Quality Standard | ISO9001 | |
Environmental Standard | ISO14001 | |
a: Gift Box b: Master Carton:Standard Export Carton c: OEM packing is available
