12V 40AH lead acid Solar gel battery
US $10.00-$38.00
Chinese best battery,Tubular solar gel battery OPzV 500ah 2v wholesale price!!
- Category: Lead Acid Batteries >>>
- Supplier: Jiangsu,Elemac,Energy,Co.,Ltd.
Share on:
Product Overview
Description
| Nominal Voltage | 2V | ||||
| Nominal Capacity (10 hour rate) | 200Ah | 400Ah | 600Ah | 1000Ah | |
| Capacity 25℃(77°F) | 20 hour rate | 212Ah | 424Ah | 636Ah | 1060Ah |
| 5 hour rate | 177Ah | 353.5Ah | 530.5Ah | 884Ah | |
| 1 hour rate | 110Ah | 220Ah | 330Ah | 550Ah | |
| Internal Resistance | ≤0.47mΩ | ≤0.39mΩ | ≤0.27mΩ | ≤0.19mΩ | |
| Capacity affected by Temperature (10 hour ) | 40℃ (104°F) | 102% | 102% | 102% | 102% |
| 25℃ (77°F) | 100% | 100% | 100% | 100% | |
| 0℃ (32°F) | 85% | 85% | 85% | 85% | |
| -15℃ (5°F) | 65% | 65% | 65% | 65% | |
| Self-Discharge 25℃(77°F) Capacity | after 3 month storage | 90% | 90% | 90% | 90% |
| after 6 month storage | 80% | 80% | 80% | 80% | |
| after 12 month storage | 62% | 62% | 62% | 62% | |
| Charge (Constant Voltage) 25℃ (77°F) | Float | Initial Charging Current Less than 30A Voltage 2.23-2.27V | Initial Charging Current Less than 60A Voltage 2.23-2.27V | Initial Charging Current Less than 90A Voltage 2.23-2.27V | Initial Charging Current Less than 150A Voltage 2.23-2.27V |
| Cycle | Initial Charging Current Less than 30A Voltage 2.33-2.37V | Initial Charging Current Less than 60A Voltage 2.33-2.37V | Initial Charging Current Less than 90A Voltage 2.33-2.37V | Initial Charging Current Less than 150A Voltage 2.33-2.37V | |
| Battery Dimensions | Length | 172mm | 211mm | 301mm | 474mm |
| Width | 110mm | 175mm | 175mm | 175mm | |
| Height | 330mm | 330mm | 330mm | 328mm | |
| Total Height | 367mm | 368mm | 368mm | 366mm | |
| Box Dimensions | Length | 186mm | 225mm | 316mm | 489mm |
| Width | 124mm | 190mm | 189mm | 189mm | |
| Height | 424mm | 425mm | 425mm | 422mm | |
| Quantity Per Box | 1 PC per box | 1 PC per box | 1 PC per box | 1 PC per box | |
| Net weight Per Cell | 13.0 kg±200g | 26kg±200g | 38.0 kg±500g | 62 kg±900g | |
| Net weight Per Box | 13.0kg | 26kg | 38.0kg | 62kg | |
| Gross Weight | 13.5kg | 26.5kg | 39.0kg | 63kg | |
1. How do you control the quality?
2. What is your minimum order quantity?
3. Can you introduce your company?
4. What are the advantages of your company?
5. Can i send samples?Report it to me along with the price?
6. How do your company deal with the problem on quality?
