Automatic networking support, a key to add equipment;
Support the Onvif protocol;
Support GB28181 (Optional);
Cloud services, P2P, alarm information push to phone;
Support remote access, support ARSP;
Support DHCP, FTP, DNS, DDNS, NTP, UPNP, EMAIL,
3G, WIFI, IP search, Alarm center, etc ;
Mobile phone remote monitoring (iOS, Android);
Multi browser access (IE, Chrome, Firefox, Safari);
Support for more than twenty languages;
Perfect protection circuit,unique triple watchdog function
Support WEB, CMS, VMS, MYEYE Platform;
Support coaxial control
Model
ADVR8016DA-LM
System
processor
Hi3531D
Video
Codec
H.265
Encode
16*1080N@15fps(6 in 1);8*1080N(6 in 1)
Decode
16*1080N@15fps(6 in 1);8*1080N(6 in 1)
Preview
16*1080N(6 in 1)
Multi-mode
Analog:16*1080N;8*1080N
Hybird:8*1080N(analog)+8*960P (network)
IP: 8*1080P+8*960P ; 4*3M;4*5M
Audio
Compression
G.711a
Intercom
Support
Management
Record mode
Manual>Alarm>Motion detection>Timing
Inquire mode
Inquire by Time/Calendar/Event/Channel
Storage mode
HDD Storage, Network Storage
Backup
Network, USB, SATA
Interface
Video input
16*BNC(Support Coaxitron)
HDMI output
1*HDMI (MAX:4K)
VGA output
1*VGA (MAX:1080P)
Audio I/O
6/1
Alarm I/O
4/1
Ethernet port
1*10/100Mbps Ethernet port, RJ45 port
PTZ control
1*RS485, Support for multiple PTZ protocol
USB Port
2*USB2.0 ports
HDD
2*SATA interface (Up to 8TB)
General
Temperature
0 ℃ - + 55 ℃
Humidity
10% -90% RH
Power supply
12V/4A
Consumption
<10W(Without HDD)
Weight
Around 1.8KG
Dimension
350m(L)* 296mm(W)* 44mm(H)
