Intumescent seals regulations/Flexible Intumescent Seal Strip/Fire Door Seals/Intumescent tape Fire Prevention seals
about us
Product Description
Price reference
thickness
specification
MOQ (roll)
By squared (dollar / m²)
3mm
1.2m/1m(Length)*10m(width)
5
15.94
5mm
1.2m/1m(Length)*5m(width)
5
23.44
GT-100TM Product Information Sheet
²Product features and functions:
GT-100TM series product is a basic type of high performance intumescent mat which mainly used in automotive catalytic converter support mount system.GT-100TM has been considered about both the price and performance during its product
development. GT-100TM is a good intumescent mat with low cost and stable performance.
GT-100TM is made of high performance ceramic fiber and bonded by organic binder. Excellent flexibility, bended nearly 180 degrees without crack. Erosion resistance of GT-100TM is excellent.
In canning applications,the fiber excellent honeycomb structure provides reliable support for the catalytic
converter at low temperature. When the temperature is above 330℃, vermiculite expands and the
thickness of the mat increases gradually, that provides a balanced, sustained and sufficient support to catalytic converter.
²Product features and functions:
l Support–Prevent substrate from shock and vibration;
l Seal-- To prevent gas leak from encapsulating gap.;
l Insulation -- Prevent overheating shell, ensure the catalyst temperature.;
l Good erosion resistance
In addition to application for automotive catalytic converter support mount system, GT-100TM can be applied to a variety of industrial insulation,including high temperature expansion ,fire prevention and other fields.
²Specifications of the products
GT-100-3100GT-100-2600GT-100-1950
Loss on ignition(LOI)@800℃(%)
4~10
4~10
4~10
Thickness (mm)
5
4
3
Application gap(mm)
3
2
1.5
Classified temperature (℃)
≤1260
≤1260
≤1260
Temperature limit (℃)
≤1050
≤1050
≤1050
Initial expansion temperature (℃)
≤450
≤450
≤450
Basis weight (g/m2)
3100
2600
1950
Minimum bending radius(mm)
≥15
≥15
≥30
Tensile strength (kPa)
≥130
≥130
≥130
² Application design and calculation
ü According to the product data which is obtained by our laboratory tests, performance in different application condition is slightly different. We recommend to calculate and verify it based on the specific application environment.
ü Please consult for more details from our sales engineer or application engineer if you are interested in any other non-standard product.
ü Have any questions or needs please feel free to contact us, our factory will provide technical support to you.
