Flexible Solar Panel Price Industry High Quality 100 W CE 3 Years,3 YEAR 0 to 5W 8kg 1000V 125*125mm
- Category: >>>
- Supplier: Longt Lighting Group INC.
Share on (60815908086):
Product Overview
Description
Model Type | LSP-6-75 | LSP-6-80 | LSP-6-85 | LSP-6-90 | LSP-6-95 | LSP-6-100 | |||||
Peak Power(Pmax) | 75w | 80w | 85w | 90w | 95w | 100w | |||||
Module Efficiency | 11.42% | 12.18% | 12.94% | 13.70% | 14.46% | 15.22% | |||||
Maximum Power Voltage(Vmp) | 18.0v | 18.1v | 18.3v | 18.4v | 18.6v | 18.7v | |||||
Maximum Power Current(Imp) | 4.17A | 4.41A | 4.65A | 4.88A | 5.11A | 5.34A | |||||
Open Circuit Voltage(Voc) Short | 21.8v | 21.9v | 22.1v | 22.2v | 22.4v | 22.6v | |||||
Circuit Current(lsc) | 4.85A | 5.10A | 5.34A | 5.58A | 5.81A | 6.03A | |||||
Power Tolerance | 0 to +5W | ||||||||||
Maximum System Voltage | 1000v | ||||||||||
Nominal Operating Cell Temperature | 44.4±2°C | ||||||||||
Maximum Series Fuse Rating | 15A | ||||||||||
Solar panel
Advantage:
High efficiency and transmission rate, low iron tempered glass,Manufacturing with IEC61215 standard
Types of solar panel:
Mono crystalline silicon & Poly crystalline silicon.
High efficiency and transmission rate, low iron tempered glass,Manufacturing with IEC61215 standard
Types of solar panel:
Mono crystalline silicon & Poly crystalline silicon.
The features
The high efficiency solar PV module adopts the world’s highest efficiency cell with efficiency up to 23%, and efficiency of the
module is 25-30% higher than the traditional ones, this cell’s positive pole and the negative pole are on the same side, the
cell’s front side can absorb maximum sunlight, so that it can get the maximum power.
module is 25-30% higher than the traditional ones, this cell’s positive pole and the negative pole are on the same side, the
cell’s front side can absorb maximum sunlight, so that it can get the maximum power.
